Aeronautical Assemblies
Permanent Fasteners
Threaded Cylindrical Bolts Manual Installation
Introduction
Nouos allons voir dans ce cours la pose manuelle des fixations suivantes :
- Hi-Lok (HL - HLR),
- Hi-Tigue (HLT),
- Hi-Lite (HST - HSTR),
La pose des fixations Pull-in (HPL) fasteners requires specific tooling and is therefore not described in this course.
Tools
Tools
Cylindrical bolt-type fasteners are installed by screwing the nut onto the threaded section. The simplest approach is to use ratchets (preferably a through-hole ratchet) with a socket.
Standard reversible ratchet
Through-hole reversible ratchet
Ratchet socket
Tools
Mais il est aussi possible to use wrenches or flat ratchets depending on the available space.
Flat ratchet
Flat ratchet offset
Combination wrench
Offset ring wrenchoffsete
Tools
It can also be held with a male hex key (known as an "Allen key") or ASTERTM if the fastener is not installed with interference fit.
Angled hex key
T-handle T
Tools
To insert a fastener that must be installed with interference fit into a hole, the following striking tools may be used.
Riveting hammer and aluminum or brass punch
Mallet with plastic tips
And of course a backing element to absorb the impact at the rear of the assembly
Plastic punch
Installation Principle
Installation Principle
Once the fastener is placed in its hole, the sequence is as follows:
- Positioning the nut.
- Tightening the nut.
- Cassure de l’hexagone d’entrainement.
Installation – Double Hexagon Nut (Hi-Lite)
Installation – Double Hexagon Nut (Hi-Lite)
Place the fastener in the hole.
Installation – Double Hexagon Nut (Hi-Lite)
Hand-tighten the nut onto the fastener. Until resistance to tightening is felt.
Installation – Double Hexagon Nut (Hi-Lite)
Hold with the male hex key and tighten on the first hexagon Until contact with the part or the required torque is reached.
Pour un montage sur mastic d’interposition non cured sealant, this first tightening on the first hexagon is mandatory to install sufficient tension to allow excess sealant to flow.
Installation – Double Hexagon Nut (Hi-Lite)
Continue tightening on the second hexagon. Until the drive hexagon breaks off.
To ensure that the breakoff is not caused by friction, the final movement before breakoff should be slow and cover an angular amplitude of approximately 20°.
Pour un montage sans mastic d’interposition ou sur mastic cured sealant, all tightening can be performed directly on the second hexagon.
La pose – Ecrou simple hexagone (Hi-Lok)
La pose – Ecrou simple hexagone (Hi-Lok)
Place the fastener in the hole.
Hand-tighten the nut onto the fastener. Until resistance to tightening is felt.
La pose – Ecrou simple hexagone (Hi-Lok)
Hold with the male hex key and tighten on the drive hexagon. Until contact.
Les Hi-Lok fasteners are not recommended for installation sur mastic d’interposition non cured sealant, without prior pinning that has allowed the sealant to flow under the same tension as the final fastener.
La pose – Ecrou simple hexagone (Hi-Lok)
Continue tightening. Until the drive hexagon breaks off.
To ensure that the breakoff is not caused by friction, the final movement before breakoff should be slow and cover an angular amplitude of approximately 20°.
La pose – Tools pneumatiques
La pose – Tools pneumatiques
For reference, some examples of power screwdrivers. The socket and key are integrated for easier tightening.
