Aidoo Pro STI

Smart Thermostat Interface​

Let's go!

Navigation instructions

Return to the beginning of the course Return to the Index Previous page Next page

Show interactive content

Click the hand icon when prompted

Play

Introduction

Click the eye icon when it flashes

Introduction

Welcome to this training course on the Aidoo Pro STI (Smart Thermostat Interface), is a solution specifically designed for the control and integration of air conditioning units through the use of a third-party smart thermostat. Not only will you learn what the Aidoo Pro STI is and how it works, but you’ll also discover:

• The various ways the Aidoo Pro STI integrates with third-party thermostats, including their specific features and applications.
• How to install, wire, and connect the device, including integration with thermostats.
• How to configure the system using the available tools, manage diagnostics, and complete the system setup process.

Now, discover how to get the most out of your device:

Let's go for it!

Index

1. Presentation of the Aidoo Pro STI

4. Integrations Aidoo Pro STI

1.1. What is Aidoo Pro? “Reminder”1.2. What is Aidoo Pro STI? 1.3. Features of Aidoo Pro STI1.4. The functionalities of Aidoo Pro STI 1.5. Differences with the current Aidoo Pro 1.6. Device elements 1.7. Consultation of compatible unit

1.1. What is Aidoo Pro? “Reminder”1.2. What is Aidoo Pro STI? 1.3. Features of Aidoo Pro STI1.4. The functionalities of Aidoo Pro STI 1.5. Differences with the current Aidoo Pro 1.6. Device elements 1.7. Consultation of compatible unit

4. Integrations Aidoo Pro STI

• 6.1. Wi-Fi setup wizard
• 6.2. Ethernet setup wizard
• 6.3. Self-diagnosis
• 6.4. Advanced configuration
• 6.4.1. Advanced settings - Information
• 6.4.2. Advanced settings - Settings

2. Assembly and Connection

2. Assembly and Connection

Videography & Additional Training Materials

2. Assembly and Connection

Let's get started!

1. Presentation of the Aidoo Pro STI

1.1. What is Aidoo Pro? “Reminder”

Aidoo is a solution that enables individual control of HVAC equipment via the Airzone Cloud app (Aidoo with an internet connection) or through home automation integration. Aidoo Pro Inverter/VRF connects AC systems from leading brands with home automation and management systems. Direct communication with the unit keeps operating statuses synchronized between the installation and the control system. Depending on your connectivity and integration needs, you can choose from different types of Aidoo Pro, such as the Aidoo Pro STI, which you’ll learn all about in this training.

DISCOVER ALL AIDOO DEVICES

1. Presentation of the Aidoo Pro STI

1.2. What is Aidoo Pro STI?

“Your Best Ally For Smart Thermostat Integration”

1. Presentation of the Aidoo Pro STI

1.4. The functionalities of Aidoo Pro STI.

Aidoo Pro HUB offers the following features:

Configurable digital input for open window or occupancy detection.

Unit control and error detection. Control options depend on the unit model and how it is configured.

Configurable digital input for open window or occupancy detection.

Automatic change of operating mode with adjustment of two set point temperatures.

Auxiliary heat control and blocking of heat sources.

Automatic change of operating mode with adjustment of two set point temperatures.

Auxiliary heat control and blocking of heat sources.

Unit control and error detection. Control options depend on the unit model and how it is configured.

Auxiliary heat control and blocking of heat sources.

1. Presentation of the Aidoo Pro STI

1.6. Device elements

Aidoo Pro STI is composed of two physically distinct elements:

Aidoo Pro STI AZAI6WP2

Indoor unit connection wire AZPV8WIRExx010

Data Sheet

1. Presentation of the Aidoo Pro STI

1.3. Features of Aidoo Pro STI

1. Presentation of the Aidoo Pro STI

1.5. Differences with the current Aidoo Pro.

Swipe the arrow

1. Presentation of the Aidoo Pro STI

1.6. Device elements

1. API Cloud
2. Local API
3. BACnet MS/TP, BACnet IP
4. Modbus RTU, Modbus TCP/IP
5. Lutron
6. Wiser/Delta Dore/Legrand
7. Voice Assistant
8. IFTTT
9. Drivers

2. Assembly and Connection

2.1. Assembly of the device

DIN rail

Screw connection

Dimensions

Funcionalidades

2. Assembly and Connection

2.2. Wiring diagram

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 1

Search for the device from the Setup Wizard.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 2

Select the Aidoo device in the Setup Wizard.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 3

Enter the device PIN code.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 4

Search for the Wi-Fi network.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 5

Select the Wi-Fi network, enter the Wi-Fi key, and press Next.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 5

Press Next.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 6

Press Next.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 7

Add Aidoo to a site or create a new site.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 1

Search for and select the Aidoo in the Configuration Wizard.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 2

Enter the PIN code for the Aidoo Pro HUB.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 3

The Ethernet connection will be detected automatically. After that, press Network Configuration to adjust the Ethernet settings if necessary, or press ‘Next’.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 4

Press Next.

3. Configuration

3.1. Configuration Wizard

You must pair the devices using the setup wizard; scroll through the images to see the step-by-step instructions:

Step 5

Add Aidoo to a site or create a new site.

4. Integrations Aidoo Pro STI

4.2. Airzone Cloud integration with Ecobee

The following shows the device's self-diagnosis:

2. Select your Aidoo.

4. Integrations Aidoo Pro STI

4.1.2. Linkage with third party account

To integrate the Aidoo Pro STI with a third-party thermostat account, follow these steps:

1. Tap the Bluetooth icon in Airtools.

1. Presentation of the Aidoo Pro STI 1.7. Consultation of compatible unit

1. Presentation of the Aidoo Pro STI 1.7. Consultation of compatible unit

Mode and temperature

Auxiliary Heating

Basic Mode: Only available with Blueface Zero thermostat connected

Digital input

Auto mode

Settings

1. Presentation of the Aidoo Pro STI 1.7. Consultation of compatible unit

Put what you have learnt to the test

1. Presentation of the Aidoo Pro STI

Videography & Additional Training Material

Here you will find the related videos, the technical datasheet, and the quick guide, so you can easily access all the information you need:

Visit the [Aidoo Pro Video Channel] for more tutorials

Quick guide

Technical datasheet Technical specifications of the meter.

Subscribe to Airzone's YouTube Channel

The new age of HVAC control

Airzone
