Copy - EN-BTCK-12-V1.6

Roadtrip

Handsfree Bluetooth Speaker for Cars

Interactive User Guide

Version 1.6

First Time Setup

Troubleshooting

< Back

Main Menu

1. Before You Start

2. How to Charger

3. Phone Connection

4. FM Connection

5. Install on Sun Visor

6. Advanced Features

7. Common Errors & Fixes

8. Register Your Product

9. Live Agent Help

10. Rate This Guide

Next

Back to Menu

< Back

Product overview

⚠ 1. Before You Start

FM Transmitter: Stream Audio to Car Speakers. Boost sound quality and volume. Auto On/Off: Disconnects when away, reconnects when back Voice Assistant: Press and hold the knob Single Connection: One phone at a time

No.

Functions

Slide to FM: Activate FM transmitter mode

Press once: Answer or end a call

Press & hold (2 sec): Reject incoming call

Press twice: Redial last number

Press & hold (2 sec): Activate phone's voice assistant

Rotate: Adjust volume or select FM channel

Press & hold (3 sec): Enter Bluetooth pairing mode

Press once: Mute or unmute microphone

Got it

Back to Menu

< Back

2. How to Charge

⚡ Charge via USB car charger 🔋 5V | 0.5-2A input 💡 LED: Flashing white while charging | Solid white when fully charged ⏱️ Full charge: 1.5 hours 🎧 Playing time: 12 hours

Next

Back to Menu

Pair your Car kit with Phone

< Back

3. Phone Connection

3.1 Pairing mode

1️⃣ Power On:

• Slide OFF/ON/FM switch to “ON”
• Paing indicator will flash 🔴🔵
• Voice indicator: “Power on” - "Pairing"

2️⃣ If LED Is Not Flashing:

• Press and Hold unitl LED flash🔴🔵 .

• Slide switch to “ON”
• LED flashes red and blue
• Voice says: “Power on” - "Pairing"

🔹 No Flashing LED?

• Hold button until LED flashes red and blue

Buttons & Indicators

Next

Back to Menu

< Back

< Back

3. Phone Connection

3.2 Search and connect

1️⃣ Enable Bluetooth on your phone 2️⃣ Search for and select "Avantree Roadtrip" ✅ You can hear"Connected"

Need help

Next

Back to Menu

< Back

4. FM Connection

Use Roadtrip as an FM transmitter. Send audio to your car by tuning to a free FM channel.

3.2 Search and connect

Connect with car stereo

Skip

换图片：显示拨到FM

Back to Menu

< Back

4. FM Connection

4.1 Switch to FM

After connecting to the phone, slide OFF/ON/FM switch to “FM”.

Next

Back to Menu

< Back

4. FM Connection

Choose FM frequency & connect

4.2 Choose FM

Choose a vacant FM frequency channel from your car radio.

Pick a vacant FM channel on your car radio.

✅ Tip: Most vacant channels contain constant static/buzz sound. These channels are commonly found below 90.0MHz and above 107.0MHz.

✅ Tip: Vacant channels usually have static. Try below 90.0MHz or above 107.0MHz.

Next

Need help

Back to Menu

< Back

4. FM Connection

4.3 Connect

Rotate the knob to match your car radio's frequency.

Next

Need help

Back to Menu

< Back

5. Install on Sun Visor

Clip the Roadtrip to the sun visor above the driver’s seat.

Next

Back to Menu

< Back

6. Advanced Features

6.1 How to Reset

1️⃣ Disconnect Roadtrip and turn off Phone's Bluetooth. 2️⃣ Hold 2s → red/blue LED flashes 3️⃣ Double-click → pink LED, 2 beeps → reset done This will clear pairing history and enter pairing mode.

Next

Back to Menu

< Back

6. Advanced Features

6.2 Activate voice assistant

🎙️ Press & hold the knob for 2s Activates Siri or Google Assistant

Next

Back to Menu

< Back

If your phone can respond to "Hey Siri" or "OK Google" without the car kit, simply press and hold the knob for 2 seconds to activate your phone's voice assistant.

6. Advanced Features

6.3 Multi-function button

Press once: Answer or end a call

Press & hold (2 sec): Reject incoming call

Press twice: Redial last number

Press & hold (2 sec): Activate phone's voice assistant

Rotate: Adjust volume or select FM channel

Press & hold (3 sec): Enter Bluetooth pairing mode

Press once: Mute or unmute microphone

Next

Back to Menu

< Back

7. Troubleshooting

🔹 Can’t hear you? Answer with knob, not phone. 🔹 Volume low? Turn up phone + Roadtrip volume. 🔹 FM noise? Use a clear channel (below 90.0 / above 107.0). 🔹 Voice assistant not working? Make sure phone is on Wi-Fi or mobile data.

👉 More Troubleshooting & FAQs ↗

跳转 p.17

Still need help? Contact support ↗

Next

Back to Menu

< Back

8. Register Your Product

Register now to:

• Extend warranty to 24 months-FREE.
• Enjoy priority service support.

Register Now ↗️

You're Ready

Back to Menu

< Back

9. Live Agent Help

We'll respond within 1 business day Quick support options:

📧 Email: support@avantree.com

Get support ↗️

📞 Schedule callback ↗️

Share your thoughts with us ↗️

📩 Submit a ticket ↗️

💬 Live chat ↗️

Back to Menu

< Back

10. Rate This Guide

Thanks for choosing HomeBuddy! We hope this guide helped you get started. Your quick rating helps us improve:
