Self-Supporting Bridge
01
The Setting
Northern Italy, early 1500s
The soldiers had marched all day. Dust hung in the air, and the sun was sinking toward the hills when they reached the river. It was wider than expected. The current was fast. The banks were rocky and steep. Horses refused to step into the water. Behind them lay miles of road. Ahead of them was their destination — a fortified town they needed to reach before dawn. The commander frowned. Without a bridge, the army would lose hours. Maybe a whole day. And time mattered. Because armies were moving everywhere across northern Italy.
The Man Who Observed
Among the people travelling with the army was a man who did not look like a soldier. He carried notebooks instead of weapons. His name was Leonardo da Vinci. Leonardo had been hired by Cesare Borgia, one of the most powerful and feared commanders in Italy. His job there was unusual: he designed machines, fortifications, and clever devices that could help the commander’s armies. And Leonardo observed everything. He studied rivers. He studied the way carts crossed wooden bridges. He studied how wood behaved when it bent or broke. His notebooks were filled with sketches. Some were maps. Some were weapons. And some were solutions to very practical problems. Like helping the army cross the river.
02
What should a bridge do?
Like you have rightly identified, bridges should be able to carry heavy loads.
Let’s test this... Take the ice-cream stick provided in your kit, and imagine it is a bridge. Hold the two ends with your hands. Now press down on the middle of the stick with your thumb.
Let’s check it...
What exactly happened?
1. You press down in the middle --> The stick bends downward. 2. The top surface gets curved and is squeezed inward (COMPRESSION). The bottom surface also gets curved but is stretched outward (TENSION). 3. A crack begins on the bottom side where tension is highest --> The crack travels further, causing failure.
TENSION
TENSION
When a bridge carries heavy loads, different parts of it experience these two forces: COMPRESSION and TENSION. Engineers design bridges such that these forces travel safely through the structure and get transferred to the supports, which finally pass the load down into the ground.
The main job of a bridge is to carry loads and safely transfer these forces to the ground.
Let’s explore how engineers design different kinds of bridges to do this job efficiently in different situations...
03
Engineering bridges
Engineers have many choices when building a bridge.They can use different materials, and they can choose from many kinds of bridge designs. But they cannot pick randomly.
Building a bridge is like solving a puzzle.
The bridge must be strong enough, big enough and stable enough - for the purpose and the location that it is intended for.
Which bridge for which situation?
movement
Show a quick summary of the video
Match these famous Indian bridges with the correct type
(Drag and drop the pics under their correct labels)
Truss
Arch
Movable
Cable-stayed
Here's an overview of just the forces, in a few types
Most bridge designs must handle both compression and tension, but Arch bridges are special because they have only compression. This happens only when the arch has the right curved shape, and when its end supports are strong.
The material matters too...
In the video, you heard the Structural Engineer describe different situations in which different materials are suitable. Here's a closer peek:
Wood has its own properties...
Bunch of straws, to help explain
Since trees grow upwards, their fibres run up and down inside the trunk — it's like a bundle of vertical straws packed together. Wood is strongest along the direction of these fibres. So beams are usually cut so that the fibres run along the length of the beam. When cut in this manner, wood handles compression quite well. But it is weak under tension. Because the fibres can compress well but they start to break apart when stretched.
Compression
Tension
That’s why the icecream stick cracked first on its bottom surface.
Now, do you see why a Wooden bridge in an Arch shape would work well?
04
Leonardo's design
Let's go back to Italy in the early 1500s...
Leonardo da Vinci wanted to come up with a bridge that met the following requirements:
It should be built very quickly, in minutes
It should not need complex tools, parts, machines or skills
It should use simple materials that are easy to find
It should be stable enough for people to cross safely
It should be easy to dismantle, so that enemies don't use it
That's quite demanding... isn't it? But he came up with a brilliant design that not only met all these requirements, but had other advantages too!
Time to take out your TinkerTime kit.
Here's how to assemble the bridge:
Did you notice that the same materials and steps get repeated over and over? That's what is called a modular design.
Here's how to assemble the bridge:
Did you notice that the same materials and steps get repeated over and over? That's what is called a modular design.
Upload a pic of your Anthotype
The brilliance of Leonardo's design
Did you realise that we did not use any fasteners? i.e., No nails, no ropes, or anything to hold the pieces together. Leonardo's original design did not even have notches that we have in our model.
The FRICTION between the sticks and the COMPRESSION forces keep the bridge together without any fasteners. Though it is technically not an arch bridge, its interlocking beams use compression to carry weights efficiently (just like an arch bridge does) - but without any supports! That's why we call it a SELF-SUPPORTING BRIDGE.
The brilliance of Leonardo's design
Now try placing 2-3 books on top of the bridge, one by one.
You'd notice that the bridge expands a bit. And mainly, it tightens more! In other words, it gets MORE stable when it bears load.. quite opposite to most other structures. When load is added, the interlocking sticks push against each other more. So, friction and compression increase - and this holds the bridge tighter. (Of course, only until a point).
The brilliance of Leonardo's design
Now look again carefully at each piece.
Let's test it.. now remove that (or ANY) one piece very carefully.. what happens?
Do you see how easy it is to dismantle the bridge if an enemy is approaching closer? You just need to remove ANY ONE stick!
But it has limitations
This bridge is suitable only for light loads (like people). It is not suitable for bigger loads like heavy vehicles - in that case, the wooden pieces slide against each other and it collapses.
It can be built only for a limited span (meaning - the distance one can cross). But Why? Can't we increase the number of sticks and make a longer bridge? Turns out, no.
Do you see that the curve can be imagined as a part of a circle? If we add more sticks, they will form a larger part of that circle, instead of spreading out in length. So, for longer bridges, we have to use sticks/logs that are much longer. That will make the bridge heavy, so more difficult to build. And more difficult to cross - since the gaps between planks will widen.
Does the bridge exist in real life?
Leonardo designed the bridge as a clever solution for soldiers to cross rivers quickly. But we don’t know if he ever built one in his lifetime. What we know for sure is that he designed and described it in his notebooks. Models of his bridge are showcased in several museums and educational centres. Some are big enough for us to climb on!
Many modern engineers and architects, like Frei Otto (German), Hermann Blumer (Swiss) and Shigeru Ban (Japanese) have built several domes and other structures that use the same principles, though these are not fully self-supported. For example:
Mannheim Mutilhalle, Germany
Wisdome, Stockholm
Centre Pampidou, France
More fun stuff...
This video provides further details of the concepts we learnt in this activity. It also shows the modular Bailey bridge - which can be constructed quickly and is actually used by armies today.
This video beautifully shows the properties of arches. It shows why a stable ground is necessary for an arch bridge. It also demonstrates how semi-circles don't make good arches.
Share your feedback for this activity
Exit
Bhogibeel Bridge
The Bhogibeel bridge is the longest road-cum-rail bridge in India. It is built over the Brahmaputra river in Assam. It is 4.94 km long.It has a 3-lane road on its upper deck and double broad-gauge railway tracks on its lower deck.
Bandra-Worli Sealink
The Bandra-Worli sea link is 5.06km long, and is located in the Mahim Bay off the Arabian Sea. It is designed to withstand earthquakes of upto 7 on the Richter scale.
The new Pamban Bridge
India's first vertical-lift railway sea bridge, Located in Tamil Nadu, it connects Mandapam in the mainland to Rameshwaram Island. This 2.7km bridge has a 72.5m long central span that lifts 17m, to allow ships to pass through.
Chenab Rail Bridge
The Chenab railway bridge is the world's highest rail bridge, with its main deck at a height of 359m above the river Chenab. It is designed to handle high rail speed, high wind speeds, as well as earthquakes upto 8 on the Richter scale.
