Next
skid steer operation
Safe Start-Up, Operation & Shutdown Procedures
Start training
What makes this machine move?
Select the 4 parts that allow it to move, lift, and tilt.
CONTINUE
What's inside the cab?
Select the controls used to operate the machine.
CONTINUE
LEVEL 1 - inspection
Check the machine to see if its safe to operate
Start
Safe to operate?
You now understand the machine. Before starting it, you must determine if it is safe to operate.
CONTINUE
Identify the unsafe condition
CONTINUE
Identify the unsafe condition
CONTINUE
level 2 - operation
Learn the basics
Start
Start the machine
You’ve completed your inspection. Now you must start the skid steer correctly. The order matters — safety systems prevent improper startup.
CONTINUE
The engine is running
Lets learn the controls
CONTINUE
Lets learn the controls
CONTINUE
Complete the operation in the correct order
Move forward, turn left, reverse and turn right. Lower the bucket, curl the bucket up, lift the arm.
Lower the bucket, curl the bucket up, lift the arm.
HINT
"We need this done safely, no shortcuts."
FINAL challenge
The crew is behind schedule. Backfill the trench before concrete arrives.
Start
Safe to operate?
Perform required pre-operation inspection. Check off the items as you complete the inspection.
CONTINUE
Start the machine
Start up the machine in the correct order.
CONTINUE
Lower the bucket, curl the bucket up, lift the arm.
Congrats! Hole is filled
You completed the task on time and safely.
CONTINUE
Machine ready
You have completed your training and are ready for the field!
restart
Step 1: Lower the Lap Bar
Sit fully in the seat. Lower the lap bar until it locks into place. Controls will not activate unless the bar is secured.
Treads / Axle
This system moves the machine and supports its weight. Treads provide traction on dirt, mud, and uneven ground and stability while lifting and turning. The axle transfers power from the drive motors to the tracks or wheels. ⚙ What to check: -Track tension - Worn tread patterns - Loose or damaged components - Debris buildup ⚠ Watch for: - Slipping or jerky movement - Uneven wear - Clicking or grinding sounds
Step 4: Start the Engine
Turn the ignition key or press the start button. Allow the engine to idle briefly. Watch the display panel for alerts. Do not rev immediately.
Step 5: Perform a Function Check
With the lap bar down: ✔ Test lift and tilt slowly ✔ Move forward and reverse slightly ✔ Confirm smooth response If anything feels abnormal — stop and inspect.
Engine Compartment
This houses the engine and core operating systems. It powers: - Hydraulic pumps - Drive motors - Electrical systems Without it, nothing moves. ⚠ Watch for: - Fluid leaks - Overheating - Unusual noises - Warning lights Routine inspection keeps the machine reliable and prevents costly downtime.
Inspecting the Tracks
Before operating: ✔ Check both tracks ✔ Remove packed mud and rocks ✔ Look for cuts, cracks, or missing tread ✔ Inspect proper track tension ⚠ Ignoring debris can lead to track derailment or costly repairs.
Step 3: Check Controls & Parking Brake
Ensure: • Joysticks are in neutral • Parking brake is engaged • No warning lights are active Confirm the machine is ready to start.
Step 1: Lower the Lap Bar
Sit fully in the seat. Lower the lap bar until it locks into place. Controls will not activate unless the bar is secured.
Left Joystick - Drive Control
This joystick controls machine movement. Move forward → Drive forward Pull back → Reverse Move left/right → Turn the machine Small movements give smoother control and better traction. ⚠ Sudden movements can cause loss of control or shifting loads.
Bucket Cylinder
This hydraulic cylinder controls bucket tilt. Extend → Bucket dumps Retract → Bucket curls back to carry It’s what lets you load, move, and unload material safely. ⚠ Watch for: - Slow tilt movement - Hydraulic leaks - Weak dumping power Smooth control = longer cylinder life.
Right Joystick — Lift & Tilt Control
This joystick controls the loader arms and bucket. Move back → Raise the arms Push forward → Lower the arms Move left/right → Tilt the bucket Use slow, controlled movements when lifting or dumping material.
Step 4: Start the Engine
Turn the ignition key or press the start button. Allow the engine to idle briefly. Watch the display panel for alerts. Do not rev immediately.
Step 2: Fasten Seatbelt
Buckle your seatbelt securely. The cab protects you — but only if you’re restrained.
Step 3: Check Controls & Parking Brake
Ensure: • Joysticks are in neutral • Parking brake is engaged • No warning lights are active Confirm the machine is ready to start.
Check for Leaks
Before starting, look beneath the machine. Fluid on the ground can signal a problem. Check for: ✔ Oil spots ✔ Hydraulic fluid ✔ Fuel leaks ✔ Coolant puddles Even small drips can turn into major failures. ⚠ Never ignore fresh fluid under the machine. Identify the source before operating.
Lift Cylinders
These hydraulic cylinders raise and lower the loader arms. Extend → Arms lift Retract → Arms lower They control vertical movement of the bucket and load. ⚙ What to check: - Smooth up/down movement - Hydraulic leaks - Damaged rods or seals ⚠ Watch for: - Slow lifting - Uneven arm movement - Sudden dropping
Step 5: Perform a Function Check
With the lap bar down: ✔ Test lift and tilt slowly ✔ Move forward and reverse slightly ✔ Confirm smooth response If anything feels abnormal — stop and inspect.
Bucket Attachment
Secures the bucket to the machine. Check before use: • Attachment seated correctly • Pins fully locked • No visible gaps • No excessive wear Loose attachment = serious hazard. Confirm. Then operate.
Step 2: Fasten Seatbelt
Buckle your seatbelt securely. The cab protects you — but only if you’re restrained.
Inspecting Hydraulic Hoses
Hydraulic hoses carry high-pressure fluid that powers the machine. Damaged hoses can fail suddenly — causing loss of control or serious injury. Before operating: ✔ Check for cracks or abrasions ✔ Look for leaks or wet spots ✔ Inspect fittings for looseness ✔ Ensure hoses are not rubbing or pinched ⚠ Never check for leaks with your hands. High-pressure fluid can penetrate skin.
