A Dive Into Cystic Fibrosis

A Dive Into Cystic Fibrosis

Interactive Learning Module

GO!

Pathology 3500: Pulse Assignment, Winter 2026Department of Pathology and Laboratory Medicine, Western University. Group #13

Table of Contents

Click each button to jump to a section! To get started, select "Introduction".

Mode of Inheritance

Pathogenesis

Introduction

Etiology

Signs and Symptoms

Diagnostic Criteria

Treatment Options

Complications

10

11

Canadian Cystic Fibrosis Research

Prognosis

Case Studies

Introduction

Let's Go!

Case Study #1

Try to find the diagnosis!

After completing this module, you will be able to revisit this case study.

Next

Introduction

What is cystic fibrosis?

• Cystic fibrosis (CF): the most common, fatal, genetic disease affecting Canadians children and young adults.

• Caused by mutations in the gene that produces the cystic fibrosis transmembrane conductance regulator protein (CFTR) (3).

• “Causes abnormally thick mucus secretions that disrupt normal molecular transport, exchange, and exocrine gland functions” (4).

--

(2)

Next

Introduction

Cystic Fibrosis Transmembrane Conductance Regulator (CFTR) Function

• CFTR: an important epithelial ion (i.e. chloride and bicarbonate) channel protein (4).

• Ion channel helps atoms or molecules with an electrical charge cross the cell membrane (5).

• Ion transport is an integral part of keeping internal body homeostasis, proper action potentials, and proper signalling.

(4)

Next

Introduction

Cystic Fibrosis Transmembrane Conductance Regulator (CFTR) Function

• CFTR in the lungs moves chloride ions from inside to outside the cell.

• After negative chloride ions move outside, they bring positive sodium ions (which brings water outside).

• Moving water out is vital to ensure mucus remains moist so that cilia in the lungs can sweep back and forth to clear debris (5).

(4)

Next

Mode of Inheritance

Let's Go!

Mode of Inheritance

Molecular Genetic Basics

• CFTR gene: located on chromosome 7.

• CF is a autosomal recessive condition (both alleles must be mutated in order to result in CF).

• Two carrier parents have a 25% chance of having an affected child (50% carriers, 25% unaffected totally) (3).

Next

(6)

Mode of Inheritance

• Allelic heterogeneity: many disease-causing mutations in CFTR identified (6).
• Different mutations in the CFTR genes can all cause cystic fibrosis, but all are located within that gene.

• Variable expressivity and genotype- phenotype correlation is observed (6).

• One mutation in the CFTR gene may not cause the same disease state as another.
• Each class of disease is defined by different mutations, with ranging severity.

(7)

Next

Mode of Inheritance

• The resulting phenotype will depend on the inherited mutation(s).

• Depending on the mutation(s) of the parent (if any), the recessive alleles of disease-affected children can be homozgyous or heterozygous.

Click on each below to learn more.

Homozygous inheritance

Heterozygous inheritance

Homozygous inheritance

(7)

Molecular Genetic Basis

Allele Homozygosity

One F508del Mutation

One F508del Mutation

• Both parents have the same mutation (F508del).

• The autosomal recessive pattern generates the following results in children:
• 25% unaffected state; no mutations inherited.
• 50% carrier state; one F508del mutation inherited.
• 25% diseased state; two F508del mutations inherited (5).

(6)

RETURN TO OPTIONS

No F508del Mutation

One F508del Mutation

One F508del Mutation

Two F508del Mutations

Molecular Genetic Basis

Allele Heterozygosity

• Both parents have different mutations.

• The autosomal recessive pattern generates the following results in children:
• 25% unaffected state; no mutations inherited.
• 25% carrier state; one F508del mutation inherited.
• 25% carrier state; one G551D mutation inherited.
• 25% diseased state; two different mutations inherited.
• Combined phenotype of F508del and G551D cystic fibrosis state.

• All carrier children are equally likely to get one mutation over the other (5).

One G551D Mutation

One F508del Mutation

(6)

Two Different Mutations (F508del and G551D)

Practise Question

One F508del Mutation

One G551D Mutation

No F508del Mutation

Test Your Knowledge #1

Next

Go Back

Etiology

Let's Go!

Etiology: Mutation Variety

Click on the button below each image to reveal mutations that cause cystic fibrosis.

CLASS I

NORMAL

CLASS II

CLASS V

CLASS IV

CLASS II

(8)

Clicking through each will allow you to advance to the next section.

NORMAL

• CFTR protein is transcribed and translated appropriately.

• CFTR is transported, processed and folded corrected, and inserted into the cell membrane.

• Proper transport of chloride (Cl-) ions into a cell, causing sodium (Na+) efflux via ENaC channels (3).

• Balance of ion transport for function.

Go Back

(8)

Click to return to mutations list

CLASS I MUTATIONS

Protein Production Mutations

• CFTR is made of 1,480 amino acids and must be assembled appropriately.

• Class I mutations: include nonsense (improper stop codon) or splicing defects (5).
• Resulting CFTR proteins are typically non-functional.

• Examples: G542X, W1282X, R553X (8).

(8)

Go Back

Click to return to mutations list

CLASS II MUTATIONS

Protein Processing Mutations

• CFTR is made of 1,480 amino acids and must be folded properly.

• Class II mutations: involve the protein's 3D conformation, internal bonds and external interacting residues.
• Resulting CFTR proteins are typically targetted for degredation within the cells and never make it to the membrane (3, 5, 8).

• Examples: F508del (most common!), N1203K, I507del (8).

(8)

Go Back

Click to return to mutations list

CLASS III MUTATIONS

Gating Mutations

• CFTR must be able to sufficiently transport ions across the membrane.

• Class III mutations: can block the 'gates' by which Cl- passes through, or never activate it to open.

• Resulting CFTR proteins are typically transported, produced and folded appropriately but cannot function.

• Examples: G551D, S549N, V520F (8).

(8)

Go Back

Click to return to mutations list

CLASS IV MUTATIONS

Conduction Mutations

• CFTR must be able to sufficiently transport ions across the membrane.

• Class IV mutations: interfere with Cl- ability to move through the 'gate' as well, and can make transport much slower or difficult.

• Resulting CFTR proteins have a mechanism to move ions, but struggle facilitating that movement (3, 5).

• Examples: R117H, D1152H, R347P (8).

(8)

Go Back

Click to return to mutations list

CLASS V MUTATIONS

Quantity Mutations

• Class V mutations: result in insufficient amounts of CFTR at the membrane surface.
• Results in a defect in any protein production and transport mechanisms (transcription, translation, processing, folding, etc.).
• Resulting CFTR proteins work properly, but ion movement is slow compared to Wild-type (3, 5).

• Examples: 3849+10kbC->T, 2789+5G->A, A455E (8).

(8)

Practise Question

Test Your Knowledge #2

Next

Go Back

Pathogenesis

Let's Go!

Pathogenesis

• Primary defect in CF: reduced production or abnormal function of CFTR.

• Caused by mutations and/or defects in transporting CFTR to the cell surface or membranes, or in the CFTR function itself.
• Disruptive mutations in CFTR render epithelial membranes relatively impermeable to chloride ions.
• Mutations in CFTR genes may cause epithelial membranes to be impermeable to chloride ions (4).

(9)

Next

Pathogenesis

• Respiratory: abnormally thick mucus can cause airway obstruction.

• Patients with CF have decreased chloride secretion and increased sodium and water reabsorption in the airways.
• Leads to dehydration of the mucus layer coating epithelial cells, defective mucociliary action, and mucous plugging (4).

(9)

Next

Pathogenesis

• Major function of CFTR in the sweat gland ducts is to reabsorb luminal chloride ions, as well as sodium reabsorption through the epithelial sodium channel (ENaC).
• CF: loss of CFTR function in the sweat duct causes increased chloride and sodium concentration in sweat.

• GI and pancreas: pancreatic duct, cystic duct, and intestinal lumen secretions become thick, obstructing each of their lumens (4).

(10)

Next

Test Your Knowledge #3

Next

Go Back

Signs and Symptoms

Let's Go!

Signs and Symptoms

Respiratory System

Digestive System

Other Systems

• Greasy stools with a bad smell (steatorrhea).
• Intestinal obstruction.
• Difficulty gaining weight.
• Rectal prolapse.
• Meconium ileus (difficulty passing first stool in newborns, causing intestinal obstruction) (11).

• Chronic, productive cough.
• Wheezing.
• Recurring lung or sinus infections.
• Stuffy nose and irritated nasal passages (11).

• Excessive salt (NaCl) in sweat.
• Fertility issues (about 98% of men are infertile and women with CF experience more fertility issues than women without CF) (11).

Next

Practise Question

Test Your Knowledge #4

Practise Question

Go Back

Test Your Knowledge #4

Practise Question

Go Back

Test Your Knowledge #5

Next

Go Back

Complications

Let's Go!

Complications

(13)

(12)

(14)

Liver

Respiratory

GI and Pancreatic

• Pathogens can colonize and multiply, causing further complications.

• Recurrent lung infections result in persistent inflammatory responses, which can lead to chronic lung issues.

• Pancreatic duct obstructions: malabsorption, maldigestion.

• Cystic duct obstructions: bile is unable to reach duodenum.

• Bile duct obstruction; hepatic steatosis, biliary cirrhosis (secondary liver damage).

Practise Question

Test Your Knowledge #6

Next

Go Back

Diagnostic Criteria

Let's Go!

Diagnostic Criteria

• To diagnose CF, both of the following criteria must be met:
• One of the following: clinical symptoms consistent with CF in at least one organ system, positive newborn screen, or having a sibling with CF.

• And: evidence of CFTR dysfunction (any of the following):
• Elevated sweat chloride (≥60 mmol/L).
• Presence of two disease-causing mutations in the CFTR gene, one from each parental allele.
• Abnormal nasal potential difference (NPD).
• Measures electrical potential across the nasal epithelium to check ENaC and CFTR function (16).

Sweat chloride test (15)

Next

Treatment Options

Let's Go!

Treatment Options

• CFTR modulators.
• Vitamins.
• Enzymes: helps the body digest fats, proteins, and carbohydrates.

• Treat respiratory complications:
• Antibiotics: treat bacterial infections.
• Inhaled medications: increase size of air passages in the lungs.

• Mucolytics: break up or thin mucus to prevent airway blockage.
• Corticosteroids: reduce lung inflammation and mucus plugging (18).

(17)

Next

CFTR Modulators

• Small-molecule medications.

• Two types:
• Correctors: improve folding and trafficking of mutant CFTR from the endoplasmic reticulum to the cell surface.
• Potentiators: increase gating function of CFTR by raising the channel-open probability (PO) to keep them open for longer (19).

(17)

Next

CFTR Modulators

• CFTR modulators depend on which mutation a CF patient has and includes (20-21):

• Kalydeco (ivacaftor).
• Alyftrek (vanzacaftor/tezacaftor/deutivacaftor): not available in Canada.
• Trikafta (elexacaftor/tezacaftor/ivacaftor).
• Symdeko (tezacaftor/ivacaftor).
• Orkambi (lumacaftor/ivacaftor).

• This module will touch upon one common modulator in detail: Kalydeco.

(17)

Kalydeco

Kalydeco (Ivacaftor)

• First-generation modulator.

• Works by potentiating the CFTR protein.

• Increases the channel-opening probability (gating) of the CFTR protein.

• Authorized for use by CF patients who are two months of age or older and have one of the following mutations: G551D, G1244E, G1349D, G178R, G551S, S1251N, S1255P, S549N, S549R, or R117H (23).

(22)

Next

Nutrition - Enzymes and Vitamins

• CF patients struggle to absorb nutrients, particularly fat.

• Enzymes help the body digest fats, proteins and complex carbohydrates.
• CF patients require increased fat-soluble vitamins (Vitamins A, D, E, and K) due to decreased absorption.
• Deficits can cause bleeding, back discomfort, bone fractures, and night blindness (24).

• Green leafy vegetable

• Liver
• Vegetable oils.
• Also produced by intestinal flora

• Liver
• Dairy products
• Egg yolk
• Yellow or green leafy vegetables

• Fish
• Egg yolk
• Fortified milk and margarine
• Liver

• Nuts
• Eggs
• Wheat germ
• Vegetable oils

Use this side of the card to provide more information about a topic. Focus on one concept. Make learning and communication more efficient.

Use this side of the card to provide more information about a topic. Focus on one concept. Make learning and communication more efficient.

Use this side of the card to provide more information about a topic. Focus on one concept. Make learning and communication more efficient.

Use this side of the card to provide more information about a topic. Focus on one concept. Make learning and communication more efficient.

Vitamin K-Rich Food

Vitamin D-Rich Food

Title

Vitamin A-Rich Food

Title

Vitamin E-Rich Food

Title

Title

Write a brief description here

Write a brief description here

Write a brief description here

Write a brief description here

Next

Test Your Knowledge #7

Next

Go Back

Canadian Cystic Fibrosis Research

Let's Go!

Canadian Cystic Fibrosis Research

"Exploring the Fetal Origins of Cystic Fibrosis Lung Disease"

“Development of Synthetic Chloride Channels and Transporters”

"Quantifying the Neurocognitive Impacts of CFTR Modulators"

• University of British Columbia: Jonathan Rayment is researching the side effects of CFTR modulators and how to relieve them.
• Patients have reported brain fog, anxiety and other mental/neuronal symptoms (25).

• Queen's University: Dr.Lee is investigating the creation of artificial compounds that might aid in the restoration of chloride ion (salt) movement in cells (25).

• University of Toronto: Amy Wong is researching how CF affects lung tissue by using lab-grown models to identify key genes and biological processes.
• Aims to determine when lung development starts to deviate from normal.
• Can lead to earlier (even prenatal) diagnosis and possibly of preventative CF medications (25).

Next

Prognosis

Let's Go!

Prognosis

• Predicted life expectancy for someone born with CF over the past few years: around 50 years old.
• Has greatly increased the median age of CF patients since in the 1980s due to treatment improvements.
• Used to be a childhood illness; has now evolved to an adult chronic condition (27).

(26)

Next

Prognosis

• Prognosis depends on the severity of disease.

• There is no cure for cystic fibrosis.

• Treatment works best with early diagnosis (highlights importance of newborn screening).
• Prenatal genetic testing can help determine whether an individual is a CFTR gene variant carrier (27).

(26)

Practise Question

Test Your Knowledge #8

Next

Go Back

Case Studies

Let's Go!

Case Study #1 (Revisited)

Try to find the diagnosis!

Title

Use this side to give more information about a topic.

Flip for answer

Cystic fibrosis

Subtitle

Next

Case Study #2 (Revisited)

Try to find the diagnosis!

Title

Use this side to give more information about a topic.

Flip for answer

Cystic fibrosis

Subtitle

Done!
