1. What is a structure
2. Functions of structures
3. Types of structures

3.1 Mass structures3.2 Trabeated structures3.3 Geodesic structures3.4 Arched and vaulted structures3.5 Trusser structures3.6 Laminar structures3.7 Cable-stayed or suspension structures3.8 Frame structures3.9 Inflatable structures

Continuar

Structures

A structure is a set of elements arranged in a way that is appropriated for supporting the weight of a body and manteining its shape, despite external forces that may act on it.

Natural and artificial structures

Continuar

Functions of structures

To design a structure we need to combine the maximum strength with the minimum amount of material, so it will be economical and lightweight. Structures have defferent purpose:

• Give shape to the object
• Protect
• Cross spaces
• Raise
• Create spaces
• Withstand forces by maintainig the shape

Continuar

Types of structures

and structural elements

1. Mass structures
2. Trabeated structures
3. Geodesic structures
4. Arched and vaulted structures
5. Trusser structures
6. Laminar structures
7. Cable-stayed or suspension structures
8. Frame structures
9. Inflatable structures

Continuar

Mass structures:

Solid, heavy and very sturdy

Trabeated structures:

Constructed with lintels

Geodesic structures:

Globe-shaped structures formed by triangles

Continuar

Arched and vaulted structures:

Stone blocks supported by their own weight

Trussed structures:

Formed by bars arranged to form triangles or trusses

Continuar

Laminar structures:

Made up of sheets that form a protective housing and support

Suspension structures:

Held in place by stay cables, usually made from steel

Continuar

Frame structures:

Formed by pillars and beams that are connected to each other.

Inflatable structures:

Formed by canvases stretched by compressed air.

Continuar

¡Thank you!

Inicio

Artificial structures

Artificial structures are, human-made formations made to meet their needs.

Examples

• Buildings
• Transportation networks
• Everyday objects
• Coastal structures

Natural structures

Natural structures are, non-human-made formations, shapes, or systems found in nature

Examples

• An animal skeleton
• Shells
• Mountains and caves
• Animal eggs
• Tree trunks
