The Problem
Until now, catheter ablation technology has been bifurcated between RF & PFA catheter solutions.
Single-Shot PFA unable to perform point-by-point
Focal point-by-point RF limited to small lesions
Multiple Catheter Workflows
RF-related Injury
Flower/Basket design cannot perform point-by-point ablation and lacks inherent stability
Limited to PFA, requires 8s charging between applications. 12F diameter requires use of proprietary deflectable sheath and has greater risk of air embolism.
Requires multiple peripherals. Not all systems are capable of mapping.
Farapulse
RF energy not titrated according to tissue temperature.
Catheter is incapable of mapping and requires additonal catheter, complicating and lengthening workflow.
3.5mm tip suffers from high current density and leads to uneven heating.
Thermacool stsf
Introducing Affera
Sphere-9 and the Prism-1 software offer safe, efficient, and efficacious solutions to existing challenges of cardiac ablation.
Revolutionary Design; Practical Implementation
Prism-1 Mapping Software.
Sphere-9 Catheter
The Console
Automatic collection | ultra high density mapping | cutting edge toolkit
All-in-one: map | ablate | validate
Sleek, integrated and compact Thoughtfully designed and expertly implemented
Ease of Use
Self-contained console
Quick Patching
Affera: 1 catheter for mapping & ablating
Thoughtfully designed with storage capacity for the entire system.
One anterior and one posterior patch monitor patient position and respiratory motion to ensure accuracy with Affera's Prism-1 Mapping software. (Ensite patching diagram pictured)
Zero-exchange workflow.
9mm nitinol focal lattice electrode
Central reference electrode
9 mini-electrodes with integrated thermocouples
Low flow central irrigation
Sphere-9: low current density, ultra high current.
Sphere-9 lattice electrode facilitates penetrating lesions with uniform heating.
Focal point-by-point PF & RF capabilities delivering durable lesions safely
Affera Ultra High Density Mapping with Prism-1
Sensor Globe gives realtime temperature feedback during ablation
Minielectrodes light up white when contacting tissue, giving vital positional data to the mapper and operator
Distance is measured from the hottest part of the last lesion and displayed.
Realtime Impedance and temperature feedback is longitudinally graphed
The operator can add custom tags through controls integrated on the Sphere-9 handle.
