Shafts and Axles: Fundamental Components in Mechanical Engineering
Shafts and Axles
shafts
Shafts are cylindrical components that transmit rotational speed and driving or resisting torques. Mechanical parts such as gears, pulleys, and brakes are mounted on them
The stresses present in a shaft are torsion, bending, and shear
brakes
gear
pulley
Types of Shafts and Axles
Shafts are classified into straight-axis shafts, which can be circular (solid or hollow) or profiled (square section, splined profile, etc.), as well as crankshafts
In shafts and axles, specific cylindrical sections called journals are identified. These are in contact with bearings, which are mounted inside the supports that sustain the thrusts transmitted to the shaft. If the direction of the acting forces is normal to the axis of rotation of the shaft, the journals and bearings are called supporting or radial, and they can be end journals or intermediate journals
X Fig. 1.3 Representation of two shafts: a) Straight splined shaft; b) Crankshaft
Shafts and Axles
axles
Axles are cylindrical mechanical components, also known simply as axles. They do not transmit torsional moments but are limited to maintaining the position of mechanical components, such as the axles of trailers and railway carriages
The stresses present in axles are bending and shear
axles of railway carriages
axles of trailers
dimensioning of shafts and axles
Load = Constant → Induced Stress (Static) is compared against the Static Allowable Stress
Fixed Axle Sizing
Load = Variable → Induced Stress (Pulsating) is compared against the Pulsating Fatigue Allowable Stress
dimensioning of shafts
If the axle rotates with the components placed on it → Alternating Fatigue Normal Stress is applied.
Rotating Axle Sizing
When bending moments are negligible compared to the transmitted torque (torsion only)→ Shear Stress is compared against the Allowable Shear Stress
Shaft Sizing
Constant Torque → Generates Constant Shear Stress →Checked against Static Allowable Shear Stress .
Torsional Stress
Variable Torque → Generates Pulsating Shear Stress → Checked against Pulsating Fatigue Allowable Shear Stress
dimensioning of axles
Pulsating Bending Stress
Rotating AxleVariable Alternating Stress → Rotating Bending Sizing (Dimensioning)
Rotating Axle Sizing
dimensioning of axles
Fixed Axle (Circular or Hollow Section) Simple Bending Sizing (Dimensioning) = Static Bending Stress.
Fixed Axle Sizing
Flexural section modulus (or section modulus for bending) of a solid circular axle section
Flexural section modulus (or section modulus for bending) of a hollow circular section
dimensioning of shafts
Solid Circular Section Shaft →Static Torsional Stress (Sizing/Dimensioning)
Solid Circular Shaft Sizing
Hollow Circular Section Shaft →Pulsating Torsional Stress (Sizing/Dimensioning)
Hollow Circular Shaft Sizing
Flexo-Torsion Case → It is necessary to consider the Ideal Bending Moment or Equivalent Bending Moment
Combined Bending and Torsion (Flexo-Torsion)
