Electric Circuits
INDEX
What is a circuit?
What is a series circuit?
What is a pararellel circuit?
What are the main characteristics of a series circuit?
What are the main characeteristics of a parallel circuit?
Thanks :D
What is a circuit ?
A circuit is a complete path around which electricity can flow. It must include a source of electricity, such as a battery. Materials that allow electric current to pass through them easily, called conductors, can be used to link the positive and negative ends of a battery, creating a circuit.
What is a series circuit?
A series circuit comprises a path along which the whole current flows through each component. In a series circuit all components are connected end-to-end,forming a single path for current flow.
What is a parallel circuit?
A pararellel circuit comprises branches so that the current divides and only part of it flows throught any branch.In a pararrel circuit,all components are connected across each other,forming exactly two sets of electrically common points.
What are the main characteristics of a series circuit?
Three rules of series circuit follow:all components share the same current;resistances add to equal a larger,total resistance;and voltage drops add to equal a larger,total votalge.
What are the main characteristics of a pararellel circuit?
-Voltage is the same across each component of the pararellel circuit.
-The sum of the currents through each path is equal to the total current that flows from the source.
Thank you so much for taking your time to watch my presentation!Love youu,don't forget that!!
-Kiara Urbaez Santana
