Agenda

El Proceso de Pensamiento Lógico

El diagrama de la Meta

El diagrama de la Realidad Actual

Las herramientas “Texto a..”

El diagrama de contradicciones

Theory Maker

El Proceso de Pensamiento Lógico Taller

El diagrama de la Realidad Futura

Marco de trabajo desarrollado por Goldratt para enfrentar problemas o proyectos en un entorno complejo.Tiene 5 etapas, y cada etapa tiene una herramienta. El proceso de pensamiento lógico nos ayuda a:

• Identificar la meta.
• Provee un proceso para identificar la raíz de los efectos.

El proceso de pensamiento lógico

Título

Usa esta cara para dar más información sobre un tema.

¿Qué es?

Subtítulo

Herramientas Texto a Diagrama

Enlace

Theory Maker

Steve Powell

Theory Maker

Mermaid

Diagrama de la Meta

Botón texto

Diagrama de la Meta (TheoryMaker)

Diagrama de la Realidad Actual

Diagrama de la Realidad Actual (TheryMaker)

Botón texto

Diagrama de resolución de conflictos

Diagrama de Resolución de Conflictos (TheoryMaker)

Ver

Diagrama de la Realidad Futura

Árbol de pre requiito

Referencias

• Powell, S. (s. f.). TheoryMaker. Recuperado de https://www.pogol.net/
• Powell, S. (s. f.). TheoryMaker (Servidor espejo). Recuperado de http://ec2-52-36-229-220.us-west-2.compute.amazonaws.com/
• ElViejo79. (2020, febrero 2). Awesome list of text-to-X. Recuperado de https://elviejo79.github.io/2020-02-02-Awesome-list-of-text-to-X/
• Siglaugsson, T. (2020). From Symptoms to Causes: Applying the Logical Thinking Process to an Everyday Problem (Kindle ed.). Independently published. Recuperado de https://www.amazon.co.uk/Thorsteinn-Siglaugsson/e/B084YSQFHW/ref=dp_byline_cont_ebooks_1

Goal; fillcolour=purple5;fontcolor=white 1 Neat, well mantained house, beautiful well sheltered garden -Critical Sucess factors; fillcolour=purple3 1.1 Neat and well mantained house 1.2 Beautiful garden 1.3 Well sheltered garden -Necessary conditions; fillcolour=purple1 1.1.1 House looks good 1.1.2 No problems with electricity, plumbing, etc. 1.1.3 All structures in order 1.2.1 Well mantained lawn 1.2.2 Neat garden 1.3.1 Trees that provide shelter -proportion=.6 ===

The pavement is uneven; colour=gray3 Tree roots have pushed up the pavement; colour=gray2 Aspen trees have strong roots that spread widely; colour=gray2 There is a lareg apen tree in my garden; colour=gray4 The is bad smell in the laundry; colour=gray3 Tree roots have broken sewer pipes; colour=gray2 Aspen trees have strong roots that spread widely; colour=gray2 Lawn is scattered with leaves; colour=gray3 Trees fell leaves;colour=gray2 I do not rake the leaves too often;colour=gray2 There is a lareg apen tree in my garden; colour=gray4 The grass does not grow well; colour=gray3 Grass needs sunlight to grow; color=gray2 There is almost always shade on my lawn;colour=gray2 Large trees cause shades; colour=gray2 There is a lareg apen tree in my garden; colour=gray4 The windows are dirty; colour=gray3 Birds shit on the windows; colour= gray2 Birds make nests in my tree; colour=gray2 Birds make nests in trees; colour=gray2 There is a lareg apen tree in my garden; colour=gray4 Bids shit close to their nests; colour=gray2

goal need1 want1 conflict awant1;colour=grey1 aneed1;colour=grey1 need2 want2 conflict awant2;colour=grey1 aneed2;colour=grey1 aneed1::assumption from the need1 goal::I have a house my neighbors admire need1::My house and garden are tides and in good order want1::Remove the tree awant1::Asumption from the want1 need2::Beutiful garden with good shelter provide daneed2::assumption from the need2 want2::Not remove the tree awant2::Assumption from the want2 conflict::conflict
