QSG - KATORCHWL-3IN1

Rechargeable 3-in-1 Multi-Function Flashlight Kit

Quick Start Guide

SKU: KATORCHWL-3IN1

Start

INDEX

• Package Contents

• Safety Information

• Device Overview

• Charging Guide

• Setup Guide

• Storage

Package Contents

Rechargable Main Body

Work Light Head

Flashlight Head

USB-C to USB-A Charging Cable

Inspection Light Head

Wall Adapter

Safety Information

• The products in the flashlight kit are not toys, and must be kept out of reach of children.

• Do not use the flashlight near flammable materials, gases, or open flames.
• Avoid using the flashlight in humid environments, high temperatures, or areas containing explosive gases.

• Only use the accessories included in the package. Do not attempt to use third party components.
• Never shine the light directly into the eyes of people or animals, especially in high-brightness modes, as it may cause eye injury.

• Always turn off the flashlight when not in use.
• Fully charge the flashlight before first use to maximise battery performance and life.

Safety Information

• Only use the provided charging cable to ensure safe and optimal performance.
• Charge the device in a well-ventilated area. Avoid charging in extremely hot or cold conditions to prevent overheating or damage.

• Ensure the power source matches the voltage requirements of the flashlight.
• Inspect the flashlight for any visible damage before use. If damaged, do not use it and contact KickAss customer service.

• The flashlight may become hot during use. Avoid direct contact with the bulb or lens to prevent burns.

• Ensure the battery cap is securely tightened to prevent the battery from coming loose or falling out during use.

Device Overview

For first time use

Please fully charge the flashlight kit before using it for the first time.

Charging the flashlight

1. Open the rubber cover, then using the included charging cable, connect the USB-C end to the flashlight’s charging port and the other end to a reliable power source.
2. The charging indicator will turn red, indicating that charging is in progress.
3. Once fully charged, the battery indicator will turn green.
4. Unplug the charging cable from the flashlight and reattach the rubber cover

Setup Guide

Attaching a Light Head1. Select the light head you want to use.2. Insert your chosen light head into the head slot of the main body.

3. An audible click will be heard to indicate that the light head has locked in place.

Setup Guide

Detaching a Light Head 1. Pull down the quick-release collar in the direction indicated by the arrow. 2. Remove the light head.

The KickAss 3-in-1 Flashlight Kit has three available head:

• Using the Flashlight

• Using the Work Light

• Using the Inspection Light

Setup Guide

Using the Flashlight 1. Attach the flashlight head to the main body. 2. Pressing the POWER/LIGHT MODE button will cycle through the following:

OFF ON/Low High OFF

Setup Guide

Adjusting the Beam Focus

• To narrow the beam and focus on a central spot, hold the flashlight body and extend the head outward until the desired focus is achieved.
• To widen the beam for broader coverage, hold the flashlight body and pull the head inwards toward the body.

Setup Guide

Using the Work Light 1. Attach the work light head to the main body. 2. Pressing the POWER/LIGHT MODE button will cycle through the following:

OFF ON/Low High OFF

Setup Guide

Tilt the work light bar to your desired angle for effective lighting.

Setup Guide

Using the Inspection Light 1. Attach the inspection light head to the main body. 2. Pressing the POWER/LIGHT MODE button will cycle through the following:

OFF ON/Low High OFF

Setup Guide

• Drag the flexible light head to your desired location for spot lighting.
• Pull or push the head to widen or narrow down the beam.

Storage

• Always store the flashlight in its case with the flashlight head attached to fit the designated slot.
• Place the two remaining heads in the designated slots.
• Place the USB charging cable in the mesh pocket.
• Charge every 3 months when not in use.

Need further assistance?

If you require further information not included in this guide, don’t worry - We’re here to help. Please contact us via the applicable Support Form provided below:

3-in-1 Flashlight Kit

To be sure that your inquiry goes to the Technical Team. Please make sure to select Technical Assistance as the enquiry type.

Go Back to Index
