QSG - KATORCHFL-WCD

LED Flashlight with Charging Dock

Quick Start Guide

SKU: KATORCHFL-WCD

Start

INDEX

• Package Contents

• Safety Information

• Device Overview

• Installing the Dock

• Charging Guide

• Setup Guide

Package Contents

List of Contents

• Flashlight
• Charging Dock
• Mounting Bracket
• Metal Clip
• USB-C to USB-A Charging Cable
• Mounting Screw and Anchor x 2

Safety Information

• The flashlight charges easily by placing it onto the docking station, which connects to a power source via a USB-C to USB-A cable.

• A strong magnetic base on the dock secures the flashlight in place for safe and hassle-free charging.

• An adjustable focus function lets you adjust the beam from a wide flood light to a focused spotlight depending on your needs.

• The built-in 4.1V 2600mAh rechargeable battery eliminates the need for disposable batteries and helps reduce waste.

• Three brightness levels (60 lumens, 250 lumens, and 600 lumens) provide flexible lighting for differing environments.

• The light beam reaches up to 250 meters, offering reliable long-distance visibility for outdoor or work-related purposes

Safety Information

• An Osram P8 LED enhances brightness, energy efficiency, and overall durability.
• A durable metal clip allows secure attachment to belts, pockets, or gear for hands free use.
• The compact and lightweight design fits easily into toolkits, glove compartments, or small storage spaces.

• An included wall-mountable plate keeps the flashlight stored in a fixed and accessible location.

• The flashlight attaches firmly to the wall plate, reducing the risk of drops, loss, or misplacement.

• Rugged construction makes it a dependable tool for professionals and everyday users

Device Overview

Setup Guide

Installing the Dock

1. Select a flat, stable surface for mounting. Make sure the area is free from flammable materials, explosive gases, electrical wiring, open flames, water, and excessive humidity.

2. Hold the mounting bracket in your desired position, keeping it level. Use a ruler or spirit level to ensure the holes are horizontally aligned.

3. Hold the mounting bracket in your desired position, keeping it level. Use a ruler or spirit level to ensure the holes are horizontally aligned.

Setup Guide

Installing the Dock

4. Drill holes at the marked points using an 8mm drill bit, then insert the provided plastic anchors firmly into the holes.

5. Align the bracket and fasten it to the wall using the two supplied screws, ensuring it is kept level.

Setup Guide

Installing the Dock

6. To attach the charging dock, align the dock’s central slot with the latch on the mount, and then twist clockwise to secure into place.

Note: Before inserting the flashlight, make sure the dock is securely attached and stable.

For first time use

Please fully charge the flashlight before using it for the first time.

Charging the flashlight

1. Using the included charging cable, connect the USB-C end to the dock’s charging port and the USB-A end to a reliable power source.
2. The battery indicator will light up green to show that the dock is ready for charging.

Note: Before docking, make sure the flashlight and charger are clean and free of debris.

Charging the Flashlight 3. Place the flashlight into the charging dock; the magnetic feature will automatically secure it in place. 4. Check the battery indicator light while the torch is in the dock to monitor the charging status:

• Red – charging in progress
• Green – flashlight is fully charged

5. Once fully charged, remove the flashlight from the dock and unplug the cable from either the dock or the power source.

Setup Guide

Using the Torch Pressing the POWER/LIGHT MODE button will cycle through the following:

Setup Guide

Using the Torch

• To narrow the beam and focus on a central spot, hold the flashlight body and twist the head clockwise.
• To widen the beam for broader coverage, hold the flashlight body and twist the head counterclockwise.

Setup Guide

Battery Status Indicator When the light is turned on: • Green Light – Battery is sufficiently charged • Red Light – Low battery; recharge is required

Belt/Pocket Clip Sturdy clip allows for easy attachment to belts, pockets, or bags for hands-free carrying.

Magnetic Base Built-in strong magnet at the bottom allows attachment to metal surfaces for hands-free use.

Need further assistance?

If you require further information not included in this guide, don’t worry - We’re here to help. Please contact us via the applicable Support Form provided below:

LED Flashlight with Charging Dock

To be sure that your inquiry goes to the Technical Team. Please make sure to select Technical Assistance as the enquiry type.

Go Back to Index

END

Setup Complete

You’ve successfully completed the setup guide of your KickAss LED Flashlight with Charging Dock.
