Ensure the fan is securely mounted on a stable surface using proper installation hardware.
Turn off the fan when not in use to conserve energy and extend product life.
Clean the fan regularly with a soft, dry cloth. Unplug or disconnect power before cleaning.
Use the built-in timer to avoid unnecessary continuous operation.
Allow adequate clearance around the fan to ensure unrestricted airflow and oscillation.
Keep fan blades clear of obstructions.
Lock fan arm securely before use.
Warnings
This fan is not a toy and must not be used around children. Children should be supervised at all times to prevent injury.
Do not touch the blades while the fan is operating.
Keep hands, hair, pets, and loose objects away from the fan while in use.
Do not place the fan too close to objects or materials that may be drawn into the blades.
Do not obstruct or block the fan blades. Prolonged obstruction may damage the motor.
Do not install the fan in areas exposed to moisture or water.
Do not use the fan if the wire is frayed, brittle, or damaged.
Do not operate the fan near heat sources such as fireplaces, stoves, or furnaces.
Do not use gasoline, thinners, or harsh chemicals to clean the fan.
Device Overview
Installing the Fan
Mounting plate
01. 02. 03. 04.
Select a stable mounting surface for the fan. Ensure it's suitable for self-tapping screws. Make sure the fan will have clear airflow, sufficient space for oscillation and collapsing, and is located away from heat, moisture, and moving parts. On the back of the mounting plate, insert the two provided nuts into the hex-shaped holes and press firmly using your fingers. While pressing the nuts with your fingers, temporarily thread the bolts halfway from the other side of the plate to secure the nuts in position.
Installing the Fan
Mounting plate
Peel off the backing of the double-sided tape on the mounting plate. Position the mounting plate on the desired surface and press firmly.Using a screw driver, secure the mounting plate with the two provided self-tappingscrews. Ensure it is tightly mounted to withstand vibration and movement. Detach the temporary bolts from step 4.
05. 06. 07. 08.
Installing the Fan
On the bottom of the fan, remove the nuts from the bolt terminals. Attach the ring terminals of the provided power cable to the bolt terminals, oberving correct polarity based on the cable pattern: Positive - stripe Negative - solid
Hard-wire connection
09. 10.
Installing the Fan
12
Reattach the nuts to secure the ring terminals in place. Route the cable neatly along the groove on the bottom side of the fan, according to your wiring setup.
11.
12.
Installing the Fan
14
13
Mounting the fan
Press the fan to the mounting plate, alligning the holes on the bottom of the fan to the mounting pins.
Once flush with the mounting plate, slide the fan base to lock the fan into place.
13. 14.
Installing the Fan
15
Mounting the fan
Insert the bolts into the mounting holes and fasten them to the pre-positioned nuts in the mounting plate. Use a screwdriver to tighten the bolts securely. Do not overtighten.
15. 16.
Installing the Fan
17
Connecting to fuse hub
Connect the positive and negative cable to a fuse hub or control panel. Protect the connection with a 5A fuse.
17.
Operating the Fan
Turning on and adjusting speed
Press the SPEED CONTROL touch button to start the fan.
Each press cycle through the following:
Operating the Fan
Using the timer function
Press the TIMER touch button.
Each press cycle through the following:
Selecting a timer option will light up its matching indicator. (3, 6, 9 or 12)
Note: The timer function can only be set when the fan is running.
Setup Complete
You’ve successfully completed the setup guide of your Kickass 12/24v 360° 3-Speed Fan (Hard-wired) is now ready to be used.
HOME
END
NEED SUPPORT?
Need further assistance?
If you require further information not included in this guide, don’t worry - we’re here to help. Please contact us via the applicable Support Form provided below:
12V/24V 360° 3-Speed Fan
To be sure that your inquiry goes to the Technical Team. Please make sure to select Technical Assistance as the enquiry type.
QSG - KA12VCABFAN
