QSG - KAJETFANMAX

Jet Blower Fan Max

Quick Start Guide

SKU: KAJETFANMAX

Start

INDEX

• Package Contents

• Safety Information

Common Problem

#X

• Device Overview

• Setup Guide

Package Contents

List of Contents

• Jet Fan
• Carry Bag
• USB-C Cable
• Inflatable Nozzle

Safety Information

• Only use the dedicated inflatable nozzle (included) when inflating airbeds, mattresses, or similar items. Using the standard blowing nozzle for inflation may cause damage and will void the warranty.
• Make sure that the inflatable nozzle is securely attached before using.
• Do not block the jet fan’s air inlet or outlet while in use.
• Do not operate the jet fan with wet hands.
• Do not expose the jet fan to moisture or liquids.
• Do not drop or insert objects into any openings of the jet fan.
• Do not place the jet fan near heat sources.
• Do not operate the jet fan near flammable substances such as gas or fuel.

Safety Information

• Do not operate the jet fan if it has been dropped or damaged.
• Never use a damaged charging cable.
• Do not disassemble the jet fan. Doing so will void the warranty.
• When cleaning the jet fan, only use a soft, dry cloth. The product is not waterproof, and water should not be used for cleaning purposes.
• Do not use sharp objects to clean the air inlet and outlets.
• Do not direct air towards eyes, ears, mouth or other sensitive areas.
• If the jet fan becomes hot and the over-temperature protection feature has activated, please allow the jet fan to cool down for at least two minutes before using again.
• The jet fan should never be left unattended while in operation.
• Keep the jet fan out of reach of children and pets.

Device Overview

1. Power/Speed Control Button

2. Speed Level Indicator

3. Charging LED Indicator

4. USB-C Charging Port

Operating the Jet Fan

POWER ON/SPEED LEVEL 1: from power off state, press the POWER/SPEED CONTROL button to turn the jet fan ON and start at speed level 1. SPEED LEVEL 2: from speed level 1, press the POWER/SPEED CONTROL button again to switch to speed level 2. POWER OFF: from speed level 2, press the POWER/SPEED CONTROL button again to turn the jet fan OFF.

Operating the Jet Fan

USING THE SPEED LEVEL 3

• From any state (power off, speed level 1 or 2), hold and press the POWER/SPEED CONTROL BUTTON to activate speed level 3.
• Releasing the button will automatically turn off the jet fan.

Note: the jet fan will not go back to the previous speed level. Once the button has been released it will turn off. If you wish to go back to the previous level, you have to press the button again until the desired level is reached.

Using the Inflatable Nozzle

• Unscrew and remove the standard nozzle from the jet fan
• Align the inflatable nozzle with the fan’s nozzle opening.

• Insert the inflatable nozzle into the opening, making sure it is properly positioned.

• Turn the nozzle clockwise until it is securely tightened.

• Confirm the nozzle is firmly attached before using the fan.

Setup Complete

You’ve successfully completed the setup guide of your KickAss Rechargeable Jet Blower Fan Max. The jet fan is now ready to be used.

HOME

END

NEED SUPPORT?

Need further assistance?

If you require further information not included in this guide, don’t worry - We’re here to help. Please contact us via the applicable Support Form provided below:

Jet Blower Fan Max

To be sure that your inquiry goes to the Technical Team. Please make sure to select Technical Assistance as the enquiry type.

Go Back to Index

END

Before you proceed

Please make sure to fully charge the jet fan before use.

For optimal charging, use the included USB-C cable with a power source that provides at least 27W.

Note: Charging the jet fan to a lower power source may result to a longer full charge duration.

I understand

When inflating beds, etc.

When using the fan to inflate items such as beds, mattresses, and other inflatables, always use the dedicated inflatable nozzle (provided). Ensure the nozzle is properly installed before operation. Using the standard nozzle or any non-compatible nozzle may damage the jet fan.

I understand

Before you proceed

Please make sure to fully charge the jet fan before use.

Using the USB-C charging cable included in the contents, connect the jet fan to a power source capable of at least 27W.

Note: Charging the jet fan to a lower power source may result to a longer full charge duration.

I understand
