Slide/Raft Relocation
start
Airbus slide/raft relocation
AIRBUS SLIDE/RAFT RELOCATION
The answer is true. All slide/rafts can be relocated to all other doors.
Airbus slide/raft relocation
AIRBUS SLIDE/RAFT RELOCATION
The answer is yes. The door should remain in the armed mode and the survival kit attached during slide/raft relocation.
B737 SLIDE RELOCATION
B737 SLIDE RELOCATION
The answer is True. Relocation of the slide is not recommended due to the possibility of inflation during removal and transportation.
B737 SLIDE RELOCATION
B737 SLIDE RELOCATION
The answer is No. Due to the girt bar length differences, slides can only be relocated to the opposite door.
B757 SLIDE RELOCATION
B757 SLIDE/RAFT RELOCATION
The answer is False. Slides at doors 3L/R cannot be relocated.
B757 SLIDE RELOCATION
B757 SLIDE/RAFT RELOCATION
The answer is True. On the B757-200, all slide/rafts are compatible with all doors.
B767 SLIDE/raft RELOCATION
B767 SLIDE/RAFT RELOCATION
The answer is Disarmed. The door should be disarmed before beginning the transfer.
B767 SLIDE/raft RELOCATION
B767 SLIDE/RAFT RELOCATION
The answer is: 1L/1R/4L/4R. The slide at 2L can be relocated to: 1L/1R/4L/4R.
B777 SLIDE/raft RELOCATION
B777 SLIDE/RAFT RELOCATION
The answer is True. Not all slide/rafts are compatible with all doors.
B777 SLIDE/raft RELOCATION
B777 SLIDE/RAFT RELOCATION
The answer is Armed. The arming lever should be in the Armed position.
B787 SLIDE/raft RELOCATION
B787 SLIDE/RAFT RELOCATION
The answer is: Pneumatic Power Assist System. The first step in the relocation procedure for the B787 is to disable the pneumatic power assist system.
B787 SLIDE/raft RELOCATION
B787 SLIDE/RAFT RELOCATION
The answer is Armed. The second step is to verify the arming lever is in the armed postion.
You have completed the Slide/Raft relocation exercise. You may close the browser at this time.
