Modbus TCP with Portenta Machine Control & Opta™
Overview & Video Tutorial
Goals
Hardware & Software Requirements
Instructions
Learn to use Modbus TCP communication on a real industrial application using a Portenta Machine Control, Opta™, a temperature sensor, and the Arduino® PLC IDE.
Final Test
Conclusion
Start
Overview & Tutorial
In the video tutorial, a Portenta Machine Control and an Opta™ micro PLC will be used as server and client respectively to share temperature information through Modbus TCP using the PLC IDE. The server will do the measurements using a type K thermocouple and the client will activate its relay outputs when a certain threshold is reached.
If you prefer to follow the tutorial in a written format, or need to review the steps and code done in the video tutorial, in the following sections you will find a step-by-step guide explaining how the temperature measurement and Modbus communication between both devices were done.
Overview & Video Tutorial
Hardware & Software Requirements
Instructions
Final Test
Conclusion
Hardware & Software Requirements
Hardware
Software
Overview & Video Tutorial
Hardware & Software Requirements
Instructions
Final Test
- Portenta Machine Control (x1)
- Opta™ (x1)
- Type K thermocouple (x1)
- Ethernet cables (x2)
- Wired internet access
- 24 VDC/0.5 A power supply (x2)
- The Arduino PLC IDE
- Portenta Machine Control - PLC IDE Activation
Conclusion
Instructions
Solution Wiring
Overview & Video Tutorial
Portenta Machine Control Setup
Hardware & Software Requirements
Modbus TCP - Server
Instructions
Opta™ Micro PLC Setup
Final Test
Conclusion
Modbus TCP - Client
Final Test
You can leave each device connected separately to the internet router or connect them together directly with one ethernet cable. The first option will let you update the preferred device remotely as you can access it through the local network.
Now you can expose the temperature sensor to some heat and monitor it from the PLC IDE. The Opta™ relay outputs and LEDs will close and turn on when the temperature surpasses the programmed thresholds respectively.
Overview & Video Tutorial
Hardware & Software Requirements
Instructions
Final Test
Conclusion
Conclusion
In this tutorial you learned how to communicate two Arduino PRO products using the Modbus TCP protocol, demonstrating a simple application of sharing temperature data to control the outputs of the devices. As you can notice, the configuration process is very straightforward and the results were as expected, being a good starting point to adapt the work done here to create your own professional solution.
Overview & Video Tutorial
Hardware & Software Requirements
Instructions
Final Test
Conclusion
Solution Wiring
- In the Portenta Machine Control: connect the thermocouple terminals to TP0 and TN0 respectively and the 24 VDC power supply to the 24-volt input and GND.
- In the Opta™ micro PLC: connect the power supply to the respective inputs on the screw terminals.
- Connect both the Portenta Machine Control and the Opta™ to your local network using ethernet cables.
Portenta Machine Control Setup
After downloading the PLC IDE, open it and create a new project for the Portenta Machine Control.
Once the runtime is flashed, navigate to On-line > Set up communication, open the Modbus properties and select the secondary serial port, then click "OK".
New project for the Portenta Machine Control
The device will show its activation status, in this case, No License as it is the first time using it with the PLC IDE. To activate it, paste the product key you bought in the highlighted box and click on Activate.
A license is needed for this product to be used with the PLC IDE, you can buy it directly from the Arduino store, and it will include the product key to activate the device.
Connect the Machine Control to the computer using a micro USB cable, the board needs to run a specific program (runtime) in order to interact with the PLC IDE. To flash it, select the device serial port and click on download.
Modbus properties
Modbus secondary serial port selection
Now, in the upper left corner, click on the Connect button and wait for the base program to be uploaded. A green Connected flag should appear in the lower right corner if everything goes well.
After the activation, the status should say OK. Now you are ready to start programming the Portenta Machine Control with the PLC IDE.
To learn more about the PLC IDE first setup, continue reading this detailed guide.
Runtime program download
Modbus TCP - Server
For the Modbus TCP configuration, on the resources tab go to the Ethernet section. As noticed, the Modbus TCP Slave mode is always enabled, so you don't have to make any changes.
Network settings for Modbus TCP
Finally, go to the main program in project and match the temperature variable with the temperature sensor lectures as follows:
Now create the variable that will be shared with the temperature sensor data in the network. Go to status variables and click on Add. Configure it as follows:
Go to the sketch editor and uncomment the library and setup function code lines. As the IP, we must use the same as the Portenta Machine Control, as it is connected to your local network, you can find it on its configurations.
In this case, the following configurations are used:
To check if everything is okay, click on compile, and if no error is shown, you can upload the code to your Portenta Machine Control.
Temperature variable setup
Next go to Temperature probes and select the sensor type, for this tutorial, enable the thermocouple connected to the first channel by setting it to true.
Once uploaded, click on the Connect button again. Now you can monitor the temp_send variable in the Watch window dragging and dropping it from the Global shared variables in the project tab.
You should see the temperature value measured by the sensor inside the "Watch" window.
Opta™ Micro PLC Setup
Once the runtime is flashed, with your Opta™ connected to your router, search for its IP address on the router configurations.
On the PLC IDE, navigate to On-line > Set up communication, activate and then open the ModbusTCP properties. Add the Opta™ IP address, then click "OK".
Now, in the upper left corner, click on the Connect button and wait for the base program to be uploaded. A green Connected flag should appear in the lower right corner if everything goes well.
Now the server is configured, create a new project, this time for the Opta™ micro PLC that will be the Client or Master.
Connecting the board
New project for the Opta™
Modbus TCP connection
The Opta™ is Pre-Licensed so you don't have to buy any license to use it with the PLC IDE
If the Opta status says No License, click on the Activate PLC runtime button to activate it. Learn more about this case in this guide.
Upload the runtime for Opta™ by selecting its serial port and clicking on the Download button as before.
Modbus TCP IP setup
Uploading the runtime to the Opta™
Modbus TCP - Client
Right-click on the device and add the FC-04 Modbus function that will let us read the server input registers.
Go to the sketch editor and uncomment the library and setup function code lines. As the IP, we must use the same as the Opta™.
In this case the following configurations are used:
With the Opta™ successfully connected to the PLC IDE, it is time to configure the Modbus TCP communication.
In the Ethernet tab, enable the Modbus TCP Master mode.
Now click on the function and in the general settings, enter the shared variable address that you defined earlier in the server,
25000
in this case.
Now go to the main code in the Project tab. Create a variable by right-clicking on the local variables window and then insert, call it temp_local and integer as the type.
Modbus TCP Master mode enabled
Then right-click on the Ethernet tab, click on Add and select the Generic Modbus device.
Finally, define the Opta™ outputs behavior in function of the temperature read from the Portenta Machine Control. To do this, go to the resources tab > Relay Outputs and give a variable name to each relay, in this case, call them
relay_1
,
relay_2
,
relay_3
and
relay_4
respectively.
In the Input Register tab, create a label for it, which could be
temp_reg
.
In the code editor, match the local variable with the shared one sent by the Portenta Machine Control.
Once stored locally, design the logic to control the outputs as you want. In this case, four different temperature levels will be set to control each output with the temperature rise respectively. Copy and paste the following script into the main code section.
On the
Generic Modbus_1
device settings, enter the Server IP, the one from the Portenta Machine Control.
The same with the LED outputs,
LED1
,
LED2
,
LED3
and
LED4
.
With the final code written, compile the project and upload it the the Opta™ micro PLC.
