Transcript

Antropometric adaptive prosthetic socket

Final Project-ENGR Lab

Gaella Muyango

Problem description

Lower back pain in lower-limb amputees to poorly fitting prosthetic sockets. Residual limb volume changes throughout the day. Current solutions are either static or require constant adjustments.

RESidual Limb and Back: targetted

Genially
Genially
THE WHY
  • Volume Changes
  • Pressure Points
  • Gait Adjustment

THE UNMET NEED

Adjustable prosthetic sockets to accommodate daily limb changes. Maintain anatomical alignment and reduce strain on the lower back. Simple, user-friendly adjustments without external tools.

The AAPS Solution

Four adjustment zones. Mechanical dials. Anatomical measurements customizing:
  • Limb circumference
  • Pressure-sensitive zones
  • Weight-bearing areas

How it Works!

Adjustment zones controlled by dials connected to internal padding. Ensures even weight distribution and comfort. Materials:
  • Breathable, moisture-wicking fabric.
  • Pressure-mapped cushioning for sensitive areas.
BIOMEDICAL ENGINEERING Fit&pressure mapping. Biomechanics.
MECHANICAL ENGINEERING Tensile dial design. Strength distribution analysis.

Reduced Back pain

BENEFITS OF THE AAPS

Better Mobility

PROtotype DEVELOPMENt

NEXT STEPS

USER TESting

conclusion
