Cantilever Bridge

Cantilever Bridge

Yannick PATOUILLARD

What is the meaning of the word "Cantilever" ? :

-Its a structural élèment -Its extends horizontally -Its supported at only one end. In french : -Catalever bridge = pont à poutre en console -Catalever beam = poutre en console

what are the characteristic of such bridge ? :

-Doesn't need external bracing or support at the free end. -Relie on the streng and rigidity of the supportting materials.

What is the usual spans of cantilever bridge ? :

Its depend on its design and materials. -Short cantilever bridge (50m to 200m). -Medium cantilever bridge (200m to 500m). -Longest cantilever bridge (can go to 1000m).

Illustration of a cantilever bridge :

Two abvantages of the cantilever bridges :

1- Long spanning capability -Can cover large spans without the need for intermediate support. 2- Efficient construction Process -Can be build in segment.

Two disabvantages of the cantilever bridges :

1- High construction Cost -Explain itself 2- Limited span for certain materials -Not the best option for extrmely long span.

Example of Cantilever bridge (the Quebec Bridge) :

Name : The Quebec bridge Location : Saint Lawrence River Type : Catilever truss bridge Construction date : 1900-1919 Probleme during construction : 2 collapse Spam lenght : -Main span : 549m -Side spans : 177m Purpose : Conecte Québec whit Lévis Record : Longest cantilever bridge in the word
