Exploring Angle Relationships in Triangles
Objectives
Start
Story
Interior Angles and Triangles
Exterior Angles
Geometric Problems
Summary
Story
Interior Angles and Triangles
The angles inside the triangle are called interior angles. For example, in triangle ABC:
Example 1:
🗨️
α, β and γ are the interior angles of △ABC
Proposition: The sum of the interior angles of a triangle is always 180 degrees.
Example 2:
In △ABC:
α + β + γ = 180° That is: 60°+60°+60° = 180°
Exterior Angles
An exterior angle is formed outside the triangle by one side and the extension of another side.
🗨️
Example 3:
In △ABC:
δ and ε are exterior angles.
In total, there are six exterior angles.
Theorem: The measure of an exterior angle of a triangle is equal to the sum of the measures of the two non-adjacent interior angles.
Example 2:
In △ABC:
δ = α + γ That is: 120° = 60°+60°
Demonstration:
β and δ are supplementary
β + δ =180°
α + β + γ =180°
β =180° - α - γ
180° - α - γ + δ =180°
δ = α + γ
Geometric Problems
Click here to draw >
Roof Inclination
If the angle at the peak of the roof is 90°, what's the inclination angle of the roof?
In order to protect from raining and snow, the roof of your house must have certain inclination (red)
90° + 2β = 180º 2β = 180° - 90° 2β = 90° β = 45°
β = 45º
Solution
1/2
Find the missing angle
2/2
Find the two missing angles.
Summary
TRIANGLE GEOMETRY
INTERIOR ANGLES
EXTERIOR ANGLES
ANGLES IN A TRIANGLE
Great job!
See you next time
Welcome 6th graders!
A journey soon begin through Social Science experiences!
8TH-EXPLORING-ANGLE-RELATIONSHIPS-IN-TRIANGLES-EN © 2024 by CASURID is licensed under CC BY-NC-ND 4.0
MATERIAL
It is highly advised to have:
- Grid paper.
- Pencils of different colors.
- Eraser.
- A rule.
- A compass.
- A Protactor.
- A calculator.
- Geogebra installed on your phone/tablet/computer (or use online version).
