Impact of the fiber orientation in composite cylindrical tubes of an external structure of a model rocket Structural simulations and optimization

Author: Joana Araújo Fiúza de Matos Supervisors: Prof. Albertino Arteiro, Guillaume dos Reis, Luís Rodrigues

Start

Index

Introduction

The model rocket

Composite layups

Material behaviour

Types of laminates

Conventional VS contemporary layup

Manufacturing of the upper motor tube

Methodology

Results

Conclusions

Introduction

The model rocket

+ info

Composite layups

CFRPs are laminates comprising the stacking of different layers of carbon fiber embedded in a polymer matrix, typically epoxy resin.

Material behaviour

Orthotropic

Quasi-isotropic

Anisotropic

Isotropic

Material that exhibit different resistance and stiffness depending on the direction of the material

Material that is isotropic only in a particular plane (within the same plane, its mechanical properties remain unchanged

Materials whose mechanical properties are unique in three mutually perpendicular directions

Material whose resistance and stiffness remain the same irrespective of the direction in which they are measured

Types of laminates

Hard laminates

Soft laminates

Most of their fibres oriented at either 45° or -45°

Most fibres oriented at 0°

Conventional VS contemporary layup

Plies of 0°, 90°, 45° and 45°

Double-double

QUAD

Set of 4 plys ±Φ±Ψ, where the values of Φ and Ψ range between 0° to 90

Manufacturing process of the upper motor tube

Material

T300/914C

Manufacturing process

Roll-wrapping process

Abaqus simulation

Manufacturing process of the upper motor tube

Define loads

Defining global seed size

Define material

Defining local seed size

Create composite layups

Define boundary conditions
