Takipsan Product Introduction

Interactive user guide and TRAINING

START!

Introduction

Hello, In this training, we will introduce you to our RFID devices, which are frequently used in the textile industry. Our main products;

• Box Station
• MiniDesk Station
• Tunnel Station
• Gate Station
• El Terminali
• Double Checker

Start Training!

Homepage

Preparation of the Label

General Information

Tunnel Station

Box Station 2

Gate Station

Mini Desk Station

Handheld Terminal

Double Checker

Label Usage - 1

If Sticker Labels are not applied correctly, they may give incorrect results, be damaged or not work at all.

How to Paste a Sticker Label Correctly?

Label Usage - 2

How to Thread Hole Punch?

If the discarded hole punch damages the RFID tag, the tag will not work.

Label Usage - 3

Stitches should be made on the black area.

How to Sew a Sewable Label?

Packaging - 1

When placing the products, care should be taken to ensure that the labels do not overlap. Additions are made in the form of one reverse and one straight. A cardboard divider should be placed between every 10 products to act as a separator.

How to Packaging Correctly?

Packaging - 2

Products should be placed in the box in an orderly manner.

How to Packaging Correctly?

General Information - 1

1.5 Meter Rule for Accurate Reading

The region where RFID reader devices will be located is very important for reading accuracy. In this regard, the antenna settings and environmental structure of the reader devices are important. The first precaution in positioning is that the reading device is 1.5 meters away from RFID tagged products.

Example

General Information - 2

Simply covering the reading area to be created with a wall structure may not block radio frequency waves. Therefore, metal fly screens or metal-painted paper can be a method to prevent radio frequency scattering.

Products with boxes or hangers (RFID Tags) are used to read the products on the devices. For example; A box/parcel containing RFID Tagged clothes is placed on the Box Station and counting is performed.

Genel Bilgilendirme - 3

When Reading Too Many Products

When Missing Product is Read

If the number of read products in the box is less than planned, it is necessary to check the RFID labeled products inside the box one by one and check whether the labels are placed in the correct order (they should not overlap), whether the RFID labels are damaged or not labeled at all.

If there are more products in the box than planned, the products must be checked one by one and the product with more than 1 label must be identified. In such cases, the information label on the parcel can also be an RFID label.

General Information - 4

Hanging Product Distance

When reading suspended RFID products, the fact that the suspended products are stuck together may cause errors in terms of the accuracy of the reading, therefore the number of hanging products should be adjusted to obtain an accurate and reliable reading.

Box Station - 1

Box Station 2

Product reading device with RFID tag inside the parcel.

• Place the device on a flat area with a desktop.
• The device is a plug and play device. Its only requirements are 220v electricity, a laptop and an internet connection.
• After the requirements are completed, the device must be energized with the start button.

I did.

In case the device does not work, please check the power and internet connection.

Box Station - 2

Takipsanplus.com

Log in by clicking here

• From the next screen, you can create a shipment, select the shipping company information, adjust the antenna settings of the device, and start and stop RFID reading.
• Place the products that come with the box on the upper surface of the device, which is the reading area, and start reading.
• Follow the information on the screen and check the accuracy of the product content.

Continue

Box Station - 3

If the Number Read is Wrong

Check for labels around.

Open the Box.

Count by 10s.

Go To Quiz

Contact the company from which you supplied the label.

If the number of tags is correct but the result is wrong, the tag does not work.

If there are too many labels, remove them.

Activity 1

00:10

Find the 4 most used areas in Takipsanplus in 10 seconds.

You can quickly select shipments opened in the past.

This is the button to add new shipment.

Antenna power and many reading settings are made here.

Starts the device. RFID reading becomes active.

Box Station Quiz

Tunnel Station - 1

TUNNEL STATİON

• It is an industrial device designed to read parcels. This plug-and-play RFID reader device requires only 220v electricity and internet connection.
• The device, which has a computer and a screen, is ready for reading after it is powered on.
• It is necessary to direct the parcels to the reading area with certain spaces.

Tunnel Station - 2

Correct Reading Rules

Boxes should not come consecutively. Before one packet is finished reading, another packet must not enter the reading area.

It is recommended that there is no RFID tag to be read within 2 meters of the device while reading.

Tunnel Station Test

GATE STATION - 1

GATE STATION

• It is used to read hanging or shelf RFID tagged products.
• This plug-and-play RFID reader device requires only 220 v electricity and internet connection.
• The device, which has a computer and a screen, is ready for reading after it is powered on.

GATE STATION - 2

Correct Reading Rules

User personnel must pay attention to the time and direction of passage through the RFID reader device.It is recommended that there is no RFID tag to be read within 2 meters of the device while reading.

Handheld Terminal - 1

Handheld Terminal

• The hanging product is a device used for reading. It contains an integrated Android device.
• Products can be read with the App developed by Takipsan.

Handheld Terminal - 2

Due to the antenna structure of the device, it can read from the surroundings, therefore it is necessary to organize the antenna power and reading area correctly.

As the antenna power is increased, the reading power of the handheld terminal increases and may give incorrect results due to the surrounding labels. The correct antenna power should be tested and adjusted according to the environment.

Mini Desk Station - 1

MINIDESK STATION

• It is a device developed to question the liveness of RFID tags.
• It has a plug-and-play system and requires a 220v electrical connection and an internet connection. When the internet connection is lost, it can keep 40,000 readings in its memory.
• It allows RFID tags to be checked one by one on the device.

Mini Desk Station - 2

Which Signal Means What?

• If the RFID tag is operational, the device will respond positively and flash a green light.

• If the tag being read has been read before, it will turn on a red light due to "Duplicate Error".
• If the tags are read twice (at the same time), the device will flash a red light due to "MultiTag Error".
• If the tag is not working, the device will not respond.

Training

Training

Double Checker - 1

What is Double Checker?

• It matches the product information tag with the RFID tag. The device reads them one by one.
• It has a plug-and-play system and requires 220v electricity and internet connection.

Double Checker - 2

Features and How it Works

• It can encode into the RFID label with the barcode information on the price tag of the products.
• If there is more than one RFID tag in the product, it disables the signaling of the other tags until only one remains.

IMPORT DATA

SCAN

Thank You

Congratulations.

Thank you for your time.

Bizimle İletişime Geçin

You have completed the guide.

Fatih Mahallesi, 1198 Sokak No: 1/A Sarnıç, Gaziemir İzmir / TÜRKİYE

This guide has been designed considering all your possible needs. However, if there is a situation you cannot solve, please contact us.
