Manuals Catagories
Tubing Tongs
Close Head Tong
Casing Tong 16-25
Back-Ups
RS Tong
Casing Tong 24-50
Tubing Spider B/C/CHD
Power Unit
Tubing Spider Mode "E"
Rod Tongs
Gear Driven Tongs
Manuals
Westco Tubing Tongs are a fast, safe, and
accurate gear driven tong for making up
and breaking out 1.315” to 5-1/2” diameter
tubing.
Features: • High Torque • Light Weight / Easy Handling • Safety Lock Front Guard • Low Maintenance Design • Proven Durability
BACK-UPS
SINGLE 5519XS-100
DOUBLE 4500ABD-100
MS MANUAL 45700
LT 55600-100
Pipe size Range: 1.05" to 6-1/8"
(26.7 mm to 155.6mm) Weight: 400 lbs (181 kg)
Pipe size Range: 1.05" to 6-1/8"
(26.7 mm to 155.6mm) Weight: 300 lbs (136.1 kg)
Pipe size Range: 1.05" to 6-1/8"
(26.7 mm to 155.6mm) Weight: 150 lbs (68 kg)
Pipe size Range: 1.05" to 4-1 /2"
(26.6 mm to 114.3 mm) Weight: 81 lbs (36.7 kg)
Manuals
Chain driven tongs
Manual
model rs-34891
The RS 34891-100 Chain-Driven tong is fast,safe, and accurate. For making up and breaking out 1.05” to 4.50” O.D. tubing. The Model RS achieves a make up torque of 4,650 lb-ft.
Features: • Safety lock Front Guard • Reinforced Steel Case Body • Desing Proven Durability • Traditional Chain Driven Design
Tubing Spiders
Manual
Westco Model’s B/C/CHD & CHD Snubbing
Tubing Spider has been proven to be an
excellent tool for safe, economical, and
trouble free handling of tubular goods. The Models B/C/CHD offer both pneumatic and hydraulic operation mechanisms, and can handle a wide range of tubing sizes.
Features: • Robust and Long Lasting
• Low Maintenance Design
• Proven Durability
Manual
tubing spider
model "e"
Westco Model E Tubing Spider has
been proven to be an excellent tool for
the safe, economical, and trouble-free
handling of tubular goods. The Model E
offers both pneumatic and hydraulic
operating mechanisms and can handle
a wide range of tubing sizes.
Features: • Robust and long lasting
• Low maintenance
• Load Rating of up to 350,000 lbs.
rod tongs
Manual
Hydraulic Rod Tongs are fast, safe,
and accurate gear driven tongs for
making up and breaking out rods.
• Model M20 Provides high RPM & low torque for shallow to medium well depths.
• Model M40 Provides medium RPM & torque for medium to deep well depths.
• Models M50 & M75 Provide low RPM & high torque for cost-efficient operation.
closed head tong
Manual
model 58-93R
Westco Model 58-93R Closed Head Tong has
been proven to be an excellent tool for the fast,
safe, and trouble-free making up and breaking
out of 1.313” to 6.063” O.D. tubing.
Features: • Traditional Chain-Drivern, Oil-Bath Lubrication System
• Utilizes the Familiar Five-Jaw Carrier Gripping System
• Includes Manual/Pneumatic Back-Up
• Low Maintenance Design
• Proven Durability
Options:
Hydraulic Back-Up Torque Arm (Stiff Arm)
Casing tongs
Manual
model 16-25
16-25 Casing Tong is a fast, safe, and
accurate gear driven tong for making up
and breaking out 4” to 16 “ diameter
casing. With a 32” handle, the tong can
produce up to 25,000 lb-ft of torque.
Features: • High Torque
• Light Weight / Easy Handling
• Safety Interlock Door System
• Low Maintenance
• Design Proven Durability
• 7 Point Contact Distribution
Casing tongs
Manual
model 24-50
24-50 Casing Tong is a fast, safe, and
accurate gear driven tong for making up
and breaking out 7” to 24“ diameter
casing. With a 48” handle, the tong can
produce up to 50,000 lb-ft of torque.
Features: • High Torque
• Light Weight / Easy Handling
• Safety Interlock Door System
• Low Maintenance
• Design Proven Durability
• 9 Point Contact Distribution
Diesel power units
Manual
model HPU-6914
Westco Diesel Power Unit is designed exclusively for generating hydraulic power in order to drive tubing, casing, and drill pipe tongs.
Features: • Unit is capable of generation pressure up to 2,900 PSI
• Power is provided by a DEUTZ air cooled, six cylinder diesel engine, type F6L 914.
• At the designed operational speed of 2,300 rpm max., the engine has a power output of 113 hp (84 kW). • The engine is rigidly mounted on a heavy duty skid.
Options: • Electric Start (Standard)
• Spring/Inertia Start
• Pneumatic Start
Dimensions:
Length : 96” (2,438.4 mm)
Width : 48” (1,219.2 mm)
Height : 56” (1,422.4 mm)
Download Manuals
45000 Tubing Tong Manual
55000 Tubing Tong Manual
56000 Tubing Tong Manual
56801-100Tubing Tong Manual
56802-100TK Tubing Tong Manual
57801-100 Tubing Tong Manual
57802-100TK Tubing Tong Manual
Download Manuals
-MS Back Up (See Tubing Tongs Manual)
-55600-LT Back-Up Manual
-55190XS-100 Back-Up Manual
-4500ABD-100 Back-Up Manual
**Right click and 'Open link in new tab'
