ZUM KIT ADVANCED
martina ortega 3B
01
introduction
The Zum Kit Advanced is a 100% real electronics education kit12. It's rugged, secure, and keeps board components and electronics in view for deeper technical knowledge12. This kit is perfect for learning how technology works with a deeper insight into mechanics, electronics, and design
COMPONENTS
- Zum Core 2.0 Board
- Infrared Sensor
- Light Sensor
- Potentiometer
- Buzzer
- Ultrasonic Sensor
- Led
- Continuously Rotating Servo
- Button
- USB-microUSB cable 1m
- Servo
- Battery holder
Zum Core 2.0 BOARD
BQ Zum Core is the board in charge of replacing Arduino Uno (or rather competing with it) although its improvements make it above it, one step away from the future Genuino 101. Zum Core is a basic board like Arduino that has an Atmel ATMEGA328P chipset with a speed of 16MIPS.
infrared sensor
Optoelectronic device capable of measuring the infrared electromagnetic radiation of objects in its field of view.
ligth sensor
It is a device that has the ability to measure the intensity of light in its environment
potentiometer
It is a resistor whose value can be modified within certain limits
buzzer
It is a small transducer capable of converting electrical energy into sound.
ultrasonic sensor
They are devices that use high-frequency sound waves to measure distances and detect objects.
led
It is a semiconductor device that emits visible light when an electric current passes through it
continuously rotating servo
Is a variant of normal servos, in which the signal we send to the servo controls the speed of rotation, instead of the angular position as with conventional servos
button
a small disc or knob sewn on to a garment, either to fasten it by being pushed through a slit made for the purpose or for decoration.
USB-microUSB cable 1m
A USB cable is a cord that allows different elements to be linked via the Universal Serial Bus (USB)
servo
It is an electric motor that incorporates a set of gears together with an electronic control circuit, in order to be able to control the rotation of said motor and thus always be able to choose the desired position.
battery
