TENSILE TESTING
01
INTRODUCTION
02
key concepts
03
Stress-strain diagram
04
Mechanical properties
05
Conclusion
In conclusion, thanks to this diagram we can know the behavior of the material in order to classify and use it depending on the properties that the material shows.
TENSILE TESTING
IT CONSISTS IN SUBJECTING A SPECIMEN TO AN AXIAL TRACTION FORCE UNTIL THE FRACTURE OCCURS
Hardness
*Is the resistance that a material opposes when trying to be scratched or penetrated
Toughness-Brittleness
* It is the ability of a material to break without undergoing elastic deformation. *Is the ability of a material to deform without breaking
Elasticity - Pl asticity
* It is the ability of a material to recover its initial shape after being subjected to deformation.
Mechanical strength
* Ability of material to resist applied forces without breaking
key concepts
Tension: is the force applied to the material Deformation: change in length of a material due to applied stress Fracture point: It is when the material breaks or fails due to the stress applied to it. Elastic limit: it is the maximum value of tension that a material supports without undergoing permanent deformation.
