Ventilation System Main Components
Air Dampercontrols and directs airflow to regulate temperature and ventilation in HVAC systems.
Air Filterremoves particles and debris from air.
Heat Exchangerenhances efficiency by transferring heat between incoming and outgoing air streams.
Return Fan balances airflow by pulling indoor air back.
Cooling Coillowers air temperature by absorbing heat through refrigerant evaporation.
Heating Coilraise air temperature using hot water or steam.
Humidifier Adds moisture to maintain comfortable humidity levels.
Supply Fan distributes conditioned air throughout the building.
