Design of a compression test bench

Weekly meeting

Start

Summary

Main axes of the project : - Testing the thermal resistance of a sleeping bag in compression - Design a test bench- Managing bench adaptability with the skin model

Schema

Frame

Heat exchanger plates

Sample

Endless screw + motor

Load cell

mettre photo prise à l'ETS

Heat exchanger plates

- Plates available at ETS too small - Where did you buy them ?

- Same material as on Créality's Ender 3D printers - Ø8mm screw, 2mm pitch - 350mm long - 42-34 motor - Provide a coupling for the 2 axes Amazon McMaster 2 in 1

Endless screw + motor

Load cell

- 4x button type - About 250 N (50lbs) resistance each - Mounted on a plate below, by screws - Zero the cell with intermediate plate and sample Amazon / McMaster

- T slotted framing - Aluminium or alloy steel - 4x 50cm - 2x 35cm - Provide connectors McMaster

Frame

Sample

- Canadian army sleeping bag - The packing index is about 2 to 4 inches (5 to 10 cm). - 12x12in (304,8x304,8mm)

Prices estimation

Price for one unity
