3D Model 1

3D Art 1: Modeling

U1 U2 U3 U4

U5 U6U7 U8

1.1.1 Modeling & Fundamentals

WARM-UP

ACTIVITY

TODAY'S

AGENDA

In the chat: Did you do anything fun this summer?

• Class Norms
• Getting to know each other
• What is 3D Modeling

CLASSROOM

EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun, don't stress
• Raise your hand to unmute

We'll start at 10:37am

I'm MS. Acker!

5 Fun Facts

1. I love to paint
2. I have two cats
3. I live in Pittsburgh
4. I like to read
5. I used to teach middle school art (This is my first year teaching High School at CCA)

This is Roger

He's our class pet

Sometimes when we are in full screen he disappears

welcome to 3D Modeling

semester long course - 8 unitsNo Art Materials - All done on Blender or Edio announcement page has everything projects are required - you MUST use blender All Projects done in class Class M,W, &F To take this course, you must have passed Digital Art

what to expect

Steps of 3D Printing:

1. Create your concept
2. 3D Modeling
3. CAM Slicing
4. 3D Printing
5. Prototype

2d vs 3d

Two Dimensional (2d): triangles, circles, squares have two dimesions- length & width

Three Dimensional (3D): cones, pyramids, sphere, cubes hace three deimsions - length width & depth

2d vs 3d

Properties of a 3D Shape

• The face of a 3D shape is a flat surface. As you will learn, the surface of a 3D model is made up of hundreds of geometric faces.

• An edge is a straight line connecting two faces of a shape.

• A vertex (plural is vertices) is a corner of a shape, or a point where three or more edges intersect.

Properties of a 3D Shape

• The face of a 3D shape is a flat surface. As you will learn, the surface of a 3D model is made up of hundreds of geometric faces.

• An edge is a straight line connecting two faces of a shape.

• A vertex (plural is vertices) is a corner of a shape, or a point where three or more edges intersect.

How many faces does this pyramid have?

Fundamentals of 3D modeling

Polygon- straight sided 2D shape that has 3 or more sides

Polygon Modeling- process of turning 2D shapes into 3D model

Fundamentals of 3D modeling

NURBS Modeling - aka Non- uniform rational basis splines

Type of 3D model that uses math formulas to creates lines in a model. Highly accurate but time consuming

3D Modeling is CAD

CAD - Computer- Aided Design

3D printing is CAM

CAM - Computer- Aided Manufacturing

Steps of 3D Printing:

1. Create your concept
2. 3D Modeling
3. CAM Slicing
4. 3D Printing
5. Prototype

why do people make 3D models?

• Interior Design
• Healthcare
• Entertainment
• Aerospace
• Tourism
• Education

EXIT TICKET:

How are you feeling about 3D Modeling?

A. Excited! B. Good C. Nervous but ok D. Oh no

WARM-UP

TODAY'S

AGENDA

ACTIVITY

• Review: What is 3D Modeling
• Uses for 3D Modeling

Think:

What is your favorite movie?....do you think they used an 3D modeling?

CLASSROOM

EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun and don't stress
• Raise your hand if you want

to unmic

1.1.2 3D Models in Today's World

REVIEW

Which Is the 3D Model?

PROPERTIES OF 3D

Faces: Flat Surface Edge: Straight line connecting faces Vertex: Corners

Review

How many faces does this cube have?

What does CAD mean?

Review

A. Computer Aided ManufacturingB. Computer Aided Design

Review:

What shape is the foundation of 3D models?

WE MADE IT THROUGH REVIEW!

How are you feeling?

3D Modeling IRL

What are some fields that might use 3D modeling?

• Developing simulations of battle fields for soldiers
• Training pilots on virtual simulators
• Getting feedback on cars before building actual cars
• Developing characters for animated movies/shows

3D Modelings &

Entertainment

Gaming

How can we use 3D models to help create games?

3D Modelings &

Entertainment

Gaming

Backgrounds and props are usually low poly

Characters are usually high poly

3D Modelings &

Entertainment

Animated Movies

Why did we switch from hand drawn animations to digital?

3D Modelings &

Entertainment

Live Action

Entertainment

Live Action

Development Pipeline

1. Molding- creating the form or primitive
2. Texturing- 2D images superimposed to creat colors and textures (almost like wrapping paper)
3. Rigging- adding a "skeleton" to make your object move

Next Class:

Topic 2: Technologies of the Trade

EXIT TICKET:

What does low poly mean?

A. A lot of detail, many polygons B. Less detail, not a lot of polygons

WARM-UP

TODAY'S

AGENDA

ACTIVITY

• Different types of programs
• Different types of models

How do you think the animation in this video looks?

CLASSROOM

EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun and don't stress
• Raise your hand if you want

to unmic

1.2.1

FORM vs FUNCTION

(How does something look vs how something works)

Do you think some of these design issues could have been avoided?

LET'S TALK ABOUT PROGRAMS

Licensed

Open Source

• Source code is public
• Security risk is higher
• Software is free to use

• Source code is not shared with the public
• Security risk is lower
• Users pay to use

Daz 3D

Open Source

SketchUp

Most popular open source 3D software!

Licensed

Houdini

ZBrush

Autodesk 3ds Max

Autodesk Maya

What does Organic Mean?

Let me know in the chat

ORGANIC

any models that are based off of living things

What are some other examples of organic models you could make?

HARD SURFACE

any models that have non moving surfaces.

ORGANIC vs HARD SURFACE

ORGANIC vs HARD SURFACE

THE LANGUAGE OF 3D MODELING

Python: Coding

• we will NOT be coding in this class
• Is not required to be a 3D modeler

However...

• Can make you more marketable when finding a job
• Useful
• Improves communication

Next Class:

EXIT TICKET:

Copyright Laws & 3D Modeling

What type of model would you recommend for a beginner?

A. Organic B. Hard Surface

WARM-UP

TODAY'S

AGENDA

ACTIVITY

• Review!
• Copyright laws

Is this character an organic or hard surface model?

CLASSROOM

EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun and don't stress
• Raise your hand if you want

to turn on your mic

1.2.2

WHAT DO YOU THINK?

You spent 3 months drawing this and post it on instagram to share with your friends...

...shortly after...you see your drawing on a tote bag in Target...you didn't have anyone ask you if it was ok, no one gave you credit, and no one paid you...

...is this ok?

Does this Happen Often?

How Would you solve this?

Does anything need done about this?

CopyRIGHT LAWS

Legal rights the creator has over their intellectual property (books, art, music, movies)

Economic Rights

Who gets paid?

Buying a shirt from an artist website?

Buying a shirt from a clothing company that an artist designed?

Buying a shirt from a company that used copyright free image?

Moral Rights

Who makes decision about the work?

You can allow or deny a movie company producting an animated adaptation of your story.

What happens if you take someone's work?

COPYRIGHT INFRINGEMENT

Recreates work and takes credit Selling/distributing copies of work without permision

Cease and desist Lawsuit filed against you

Am I allowed to follow tutorials or make fan art?!!

3D PRINTING?

Creating your own design

Using someone else's Design

vs

Patent free design

Paid to use design

Educational use

Copyright is for art Patent is for inventions

Taken, claimed as own, sold

Next Class:

EXIT TICKET:

Taking someone else's design & selling it as your own is called what?

A. Copyright infringement B. Patent

WARM-UP

TODAY'S

AGENDA

ACTIVITY

• Perspective
• Reminder: if you participate in class you can submit blank

Think: How do you make a 2D drawing look 3D?

CLASSROOM

MATERIALS:

EXPECTATIONS

• Optional:
• Pencil & Paper

• Be kind and respectful
• Ask questions
• Have fun and don't stress
• Raise your hand if you want

to unmute

1.2.3

WHAT ABOUT BEFORE 3D MODELS?

We used perspective

What is perspective?

PERSPECTIVE- HOW YOU VIEW SOMETHING

• Can make 2D art look 3D
• (like an illusion)

• Can give us clear idea of what something will look like

WHY WOULD WE NEED TO SEE SOMETHING FROM ALL ANGLES?

Let me know in the chat

WHY WOULD WE NEED TO SEE SOMETHING FROM ALL ANGLES?

What could be on the backside of this house?

*In edio there is a drawing section. If you attend class you can submit blank

LINEAR PERSPECTIVE

aka

One Point Perspective

All angles are pointed towards one center point

Zoom Poll:

Have you ever heard of this before?

Do you notice anything about this photo?

LINEAR PERSPECTIVE

aka one point perspective

• Vanishing point
• Horizon
• Orthogonal lines

LINEAR PERSPECTIVE

aka one point perspective

Stamp the vanishing point

LET'S MAKE OUR OWN

Linear perspective drawing

Reminder:

If you attend guided you can submit blank

Art Gallery

IS ALL ART 1 POINT PERSPECTIVE?

What if there are 2 vanishing points?

What is that called?

TWO POINT PERSPECTIVE

2 vanishing points

WHAT IF THERE ARE 3 VANISHING POINTS?

What is this called?

Next Class:

Unit 1 Test

• Reviewing with Gimkit
• Time to take test in class & ask questions

Study Guide & Notes in Homepage

WARM-UP

TODAY'S

AGENDA

ACTIVITY

• 1 round Gimkit
• Rest of class open to take test/ask questions

Visit: 3D Art homepage FIND THE STUDY GUIDE!

CLASSROOM

EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun and don't stress
• Raise your hand if you want

to speak

1.3.1

How to Study?

1. Study guide 2. Edio review 3. Gimkit in class

UNHAPPY WITH TEST GRADE?

• I can reset you into a different version of the test

Before you retake the test, make sure to look at the study guide

Let's play 1 round of...

If you have already taken the test you are free to go

For the rest of class...

TAKE THE TEST

I'm here if you need any help!

Feel free to come & go until the end of class as you need

EXIT TICKET:

I understand that I cannot submit blank today

A. Yup! I'm taking the test! B. Now I know!

2.1.1

Today's Agenda

• Surface vs Solid models
• Polygons
• Wireframe

WARM UP ACTIVITY

Create your own model! https://toytheater.com/build/

CLASSROOM EXPECTATIONS

• Be kind and respectful
• Ask questions
• Have fun, don't stress
• Raise your hand to unmute

Vocabulary

• High-poly
• Low-poly
• Mesh sctructure
• Parametric
• Polygonal Models
• Surface Model
• Solid Model
• Wireframe Model

TWO BASIC MODELS

Surface Models

Solid Models

Only represents suface (or exterior)

Represents surface & volume ​

Complex structures built usinng mathmatical equations

Like a shell

SOLID MODEL

Used by engineering, manufacturing, and medical industries

• Mathmatically accurate models
• More complicated interiors
• Longer to render
• Not as focused on the aesthetic

SOLID MODEL

What is taking up all that space?

• Teeny tiny mesh structure
• Includes a lot of vertex points
• Longer to render

• Parametric- strict rules or perameters to build the model based on what the model is going to be used for

WE MADE IT THROUGH OUR FIRST TEST!

How are you feeling?

A surgeon is planning a Kidney transplant...

Do you think they'll use a Solid or SURFACE MODEL?

SURFACE MODEL

Used for games & animated movies

• Has less vertexes & information
• Can render quicker
• Appearance is more important than accuracy

Different types of

SURFACE MODELS

Polygon

*Shape with 3 or more edges

Wireframe

Does not include Faces

Low poly MODELS

Uses less polygons

How do these look?

Polygon is a shape that has 3 or more sides

High POLY MODELS

Uses more polygons

Polygon is a shape that has 3 or more sides

Which Do you prefer?

review

Surface model:

Low Poly Model:

• Used by animators
• Simple mesh
• Known as shell models

Includes polygon & wireframe

• Uses less polygons

Solid model:

• Used by engineers, manufacturing, medical

• Parametric
• Includes surface & volume

High Poly Model:

• Uses more polygons

exit ticket

What type of model would you use to make a video game?

byeeeee

next class

When to use models

2.1.2

Today's Agenda

• Review different types of models
• Techniques of models

Think...

• Do you think they sketched out this design before creating the animation?

CLASSROOM EXPECTATIONS

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

LET'S REVIEW!

TWO BASIC MODELS

Solid Models

Surface Models

Animation, Video Games, Art

Engineering, MAnufacturing, Medical

Only represents suface (or exterior)

Represents surface & volume ​

Like a shell

Complex structures built usinng mathmatical equations

SOLID MODEL

Used by engineering, manufacturing, and medical industries

• Mathmatically accurate models
• More complicated interiors
• Longer to render
• Not as focused on the aesthetic
• Parametric- mathmatically accurate

SOLID MODELS

Let's Review:

Zoom Poll:

What type of model would you use to create an animation?

SURFACE MODEL

Used for games & animated movies

• Has less vertexes & information
• Can render quicker
• Appearance is more important than accuracy

Different types of

SURFACE MODELS

Polygon

*Shape with 3 or more edges

Wireframe

Does not include Faces

PRIMITIVES

BUILDING BLocks for all models - Basic shapes to create your design

**We will use this phrase the rest of the course

Let's Review:

In the chat:

What primitives make up this robot?

Modeling Techniques

Parametric- follow specific mathmatical parameters (set of rules)

Polygonal- putting together 2D polygons to create 3D models

NURBS- (Non-uniform rational basis splines) uses mathematical forumulas to calculate surfaces

Digital Sculpting- pushing and pulling the model like clay

Parametric

follow specific mathmatical parameters (set of rules)

Why would a car engine need to be accurate?

True or False: Minecraft is polygonal

Polygonal

SCULPTING

pushing and pulling the model like clay

NURBS

(Non-uniform rational basis splines) uses mathematical forumulas to calculate surfaces

WE DID IT!

Review:

Surface vs Solid Model Primitives Modeling techniques

exit ticket

BYEEEE!

What type of model would you use for medical purposes?

next class

Production Workflow

Today's Agenda

• Review- Who uses 3D models?
• Workflow
• Pre production
• Production
• Post production

Think...

• Do you think the sketch helped with the design?

CLASSROOM EXPECTATIONS

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

2.2.1

Who uses models?

Architects

Why would architects (people who design buildings) need to use 3D models?

Who uses models?

Medicine

Useful for planning, transplants, predicting outcomes

Who uses models?

Entertainment

What is your favorite entertainment use of 3D models? a. movies b. games c. short form (tiktok, reels, music videos, edits) d. shows

We Made it Through Review!

Production workflow

(Step by step process to creating a model)

Pre-Production

Production

Post-Production

Pre-Production:

Creating

Before

• Fleshing out ideas
• Planning a rough design
• Selecting a type of 3D model and technique
• Creating a style guide

Pre-Production:

Fleshing out ideas- planning out design

Pre-Production:

Creating a style guide

Pre Production

Why is pre production important?

Production

Creating

• Buidling a 3D layout
• Creating a 3D model
• Applying a texture to 3D model

Production

Creating

Do you think the tree would look the same without texturing?

Post Production

After

Creating

• Lighting - adding lights
• Rendering - final assembled animation scenes or pieces out of the program
• Compositing - Editing each render output for settings like brightness, contrast, colors
• Color Correction - Adjusting darkness, brightness, color contrasts

Post Production

After

Creating

WE DID IT!

Review:

Careers that use models Production workflow Pre production Production Post production

exit ticket

BYEEEE!

Planning is part of pre productionTrue or False

next class

Gimkit & Test

Today's Agenda

• Gimkit

CLASSROOM EXPECTATIONS

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

2.3.1

How to Study?

1. Study guide 2. Edio review 3. Gimkit in class

UNHAPPY WITH TEST GRADE?

• I can reset you into a different version of the test

Before you retake the test, make sure to look at the study guide

Let's play 1 round of...

If you have already taken the test you are free to go

For the rest of class...

TAKE THE TEST

I'm here if you need any help!

Feel free to come & go until the end of class as you need

exit ticket

MATERIALS NEEDED

VDI downlaod in edio

next class

Starting AutoCAD

3.1.1 Downloading Blender

Today's Agenda

Downloading Blender using VDI

Materials:

• VDI in Edio
• Your login info

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• How many primitives did the artist use for this 3D model?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

Virtual Desktop Interface

VDI

Click on VDI in EDIO

exit ticket

MATERIALS NEEDED

Were you able to download Blender?

Blender

next class

Blender Interface

3.1.2 Blender Interface

Today's Agenda

• Downloading VDI
• Blender interface

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Were you able to get Blender downloaded?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

exit ticket

MATERIALS NEEDED

None

Blender

next class

Blender Basic Tools

3.1.3 Shading in Blender

Today's Agenda

Adding/Removing ShapesShading Smooth

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• None

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

exit ticket

MATERIALS NEEDED

None

Blender

next class

Assignment: Create a Robot

3.2.1 Assignment: Design a Robot

Today's Agenda

Designing a robot in Blender

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• None

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

exit ticket

MATERIALS NEEDED

None

Blender

next class

Moving, Rotating, and Scaling

4.1.1 Moving Rotating, & Scaling

Today's Agenda

Basic controls in Blender

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• None

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

CCA T-SHIRT CONTEST

Details in your email

• Optional
• 2-3 colors
• maximum dimensions 9" x 9"
• submit in form in email
• Winning entry will receive CCA prize back and T Shirt
• Deadline 3/18 at 9AM

NO CLASS FRIDAY

Recording will be posted

• We will cover "edit mode" in Friday's lesson
• I will introduce basics in todays lesson

exit ticket

MATERIALS NEEDED

I understand I must have access to Blender for the rest of the course

Blender

next class

NO CLASS - Recording will be posted

4.1.2 Edit Mode in Blender

Today's Agenda

Edit Mode Blender

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Do you see any similarities between Blender and Tinkercad?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

exit ticket

MATERIALS NEEDED

I understand I must have access to Blender for the rest of the course

Blender

next class

Exploring edit Mode

4.1.3 Exploring Edit Mode

Today's Agenda

Create a pencil in Blender

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Do you recognize any of the tools used?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

exit ticket

MATERIALS NEEDED

I understand I must have access to Blender for the rest of the course

Blender

next class

Adding Modifiers

What does modify mean?

4.1.4 Adding Modifiers

Today's Agenda

Context menuModifier Tab Subdivision

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Do you recognize any of the tools used?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

MATERIALS NEEDED

Blender

next class

Modifier Stacks

4.2.1 Adding modifiers Stacks

Today's Agenda

Modifier TabStacking modifiers

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Do you recognize any of the tools used?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

MATERIALS NEEDED

Blender

next class

UV Mapping

4.2.2

Today's Agenda

What is texture?adding texture UV Tab

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• What makes this look so realistic?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

What is texture?

Pick a Texture

1. Go to google images
2. Look up whatever texture you like!
3. Right click "save"
4. We will use this texture in Blender

Keep track of where you save it!!

MATERIALS NEEDED

Blender

next class

COLOR!!!

4.2.2

Today's Agenda

Adding colorReviewing texture

Materials:

• Blender

CLASSROOM EXPECTATIONS

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

Lighting & Mood

Lighting & Mood

What is the mood in this photo?

Lighting & Mood

What makes this ally scary?

Lighting & Mood

Where is the light source in this photo?

Light source - means where the light comes from

Lighting in Blender

MATERIALS NEEDED

Blender

next class

Rendering

4.2.2

Today's Agenda

ARendering Post Production

Materials:

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• What makes this look so realistic?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

Announcements:

• VDI is now working
• you can still use the Blender you downloaded to your computer

• I will not be here this Friday
• I will leave a recording

Pre Production

PRoduction WOrkflow

• Planning
• Choosing style
• Choosing colors

Production

• Creating the models
• Adding colors and textures
• Adding light

Post Production

• Editing after rendered

Rendering Engines

EEVEE vs Cycles

Eevee

• Quicker render

• Best for low poly

Cycles

• Longer render
• More realistic
• Great for lighting

4.3.2

Today's Agenda

Project - you can NOT submit blank today

Materials:

I will demonstrate how to do the project in class

• Blender

WARM UP QUESTIONS

CLASSROOM EXPECTATIONS

• Do you think this would look as cool without the lighting and color?

• Be kind and respectful
• Ask questions
• Don't spam the chat
• Have fun

Announcements:

• VDI is now working
• you can still use the Blender you downloaded to your computer

What are we doing?

Creating a simple basket

1. Create basic shape of basic using transform tools
2. Put holes in basket using modifiers
3. Put texture on basket
4. Adding light source *optional

Can i Submit Blank?

No- this is a project

Go into Edio

or

Get a basket texture from google

MATERIALS NEEDED

Remember - you have to turn in work today

BlenderPencil & Paper

next class

Bring your sketches to life
