1.Zum care 2.0

Units: 1Microcontroller: ATMEGA328PB Voltage: 5V (3A) Input voltage: 6 – 15 V Analog I/O: 6, digital: 16 Interfaces: Bluetooth Low Energy 4.2 (115200 bps), USB, ICPS, TTL UART, SPI, I2C (2 ports)

2. Infrared sensor

Units: 2Voltage: 5V Pin Definition: 1-Signal 2-VCC 3-GND Interface: Analog Fast response and high sensitivity Weight: 4g

3. light sensor

Units: 13 pin connector Pin Definition: S-Signal V-VCC G-GND Weight: 4g

4. potentiometer

Units: 1Voltage: 5V interface: analog Pin definition: S-Signal V-VCC G-GND Sensor rotation: 300º Weight: 4g

5. Buzzer

Units: 1interface: analog Pin definition: S-Signal V-VCC G-GND Fast response and high sensitivity Weight: 4g

6. ultrasonic sensor

Units: 1Pin Definition: S-Signal V-VCC G-GND Weight: 8g Range: 3 – 400cm Resolution: 0.2cm Effective angle: 15º

7. led

Units: 2Voltage: +3.3 – 5V Pin Definition: 1-Signal (yellow) V-VCC (red) G-GND (black) Weight: 5g

8. Continuous rotation servo

Units: 2Voltage: 4.8-6V Torque: 3.0/5.1 Kg.cm (4.8V/6V) Speed: 43/54rpm (4.8V/6V) Weight: 41g

9. Button

Units: 1Weight: 4g

10. USB-microUSB cable 1m

Units: 1Weight: 31g

11. Servo

Units: 2Voltage: 4.8-6V Torque: 1.5 – 1.8 kg.cm Speed: 0.12 – 0.10 s/60º Weight: 8.5g

12. Battery holder

Units: 1Hollow for 8 AAA batteries black color Weight: 20g

EXERCISEs

00. Bliking Led

At a certain time the led has to turn on and stay on for a while, then it goes off for a while and turns on again.

01. Led + Button

02. Led + Light Sensor

03. Led + Button + Light Sensor

04. States Machine

04. States Machine

idjidpci

06. traffic lights

jhdsigh

06. traffic lights

0.7 ultrasounds
