DMAIC

FLASH V1

DMAIC Project

Quality & Continuous Improvement Management

Phase: EFINE

Define baseline, objectives and work team

Business case

V1 With more than 200 defect on 26 molds validated (Jan-Feb 2023)

GOALS

+ Info

Reduce flash on molds by 30%

Objectives

KR

Without flashes on plastic part of validation 1

Key Results

Team Work

Roles and responsibilities

Rafael Delgado

Andres Lopez

Q &C.I. ManagerProject development / Black Belt

Programming LeaderMachining strategies

Carlos Estrada

Patricia Cruz

Shop ManagerDefinition of variables / Mold Making Expert

Quality System Sr CoordinatorAnalysis of variables / Documentation of improvements

Joe Jeffrey

Francisco Olan

Manufacturing ManagerVariable definition/ Machine Expert

Continuous Improvement EngineerAnalysis of variables/design of experiments/analysis of results

Ruben Rodriguez

Christian Mora

Schedule Manager Time planning / Machines

Maitenance Coordinator Machine analysis/TPM

Miguel Garrido

Carlos Ramirez

Job Logistic CoordinatorV0 results in molds / Root cause analysis

MM-Spotting Supervisor Definition of problem/spotting times

Base line

Major flaws in V1

Data obtained from 26 molds with V1 during Jan-Feb 2023Major defect present:

• Flash (296 issues)

+ Info

Goal 1

Potential process variables

potential variables to analyze

• Type of tool used (flat/ball/etc)
• Tool Life (Wear)
• Machining strategy (lack of standardization in programmers)
• Enviroment temperature (3° - 30°)
• Rommer arm (variation between measurements)
• Holder condition (tool state)
• Screw temperature (Index of thermal expansion)
• TPM (Machine in optimal conditions)
• Seal type (flatness, angle, slope and transition actors)

Goal 1

Define process variables

Variables to analyze

Review machining strategies:

• A) Diferent strategies of programs
• B) Program diferents surfaces
• C) Create core/cavity test block (Promac VT/Promac 001/Promac 004/ DMG 125U)
• D) Analyze spotting on test block
• E) Run MSA for rommer arm
• F)Validate TMP before and after use to machine
• G) Define good machining practices (use of RTCP more frequently)

Variables and strategies

Test blocks 1 & 2 Set A

Results

Test blocks 1 & 2 Set A

Axis PARALLEL

Chord error

reductions

45°

0.00004”

5 Axis

Results

Learned lessons (Machining strategies)

Test Block

Shift A-B

Learned lessons (Mold Making)

Test Block

Set 1

Seal test in test block °2

Machined with a very good finish on stamp and figure, vibrated finish on boxes (machine problem), the stamp is achieved by retouching verticals and radii.

Advance in strategies for machining

7 hours

Machining time

57%

Variation between zones

1 hour

adjustment time

Spotting Test

Key Points

• Seal zones A-B-C make contact at the same time
• Only verticals and angles are touched
• Test shows clip displacement, should be corrected for next test
• Machine finish good for polishing
• Steps can be seen in the area of the plastic piece (near the wall)

Next Steps

Step 1

step 4

step 3

STEP 2

step 1

Perform spotting test and collect new data

Duis autem vel eum iriure dolor in hendrerit in

Make corrections in programming and machining strategy

Carry out planning and test machining

Request advice from Gustavo Barrera for design modification

+info

¡Thank You!
