Energy Diagrams
Introduction
Energy diagrams are graphical representations of the energy changes that occur during a chemical reaction or a physical process. They show the relative energy levels of the reactants, products, and any intermediate species involved in the reaction, as well as the activation energy required for the reaction to occur.
Parts of an energy diagram
The y-axis (energy): The y-axis on an energy diagram represents energy, typically in units of kilojoules per mole (kJ/mol). The energy scale is often relative, meaning that the absolute energy values are not as important as the relative differences between them. The higher the energy value, the less stable the species is.
The x-axis (reaction progress): The x-axis on an energy diagram represents the reaction progress, usually in terms of the reaction coordinate or the extent of the reaction. This can be represented by the bond distance, reaction time or any other quantity that represents the progress of the reaction. The reaction coordinate can be linear or curved depending on the reaction mechanism.
Parts of an energy diagram
Reactants: The reactants are the starting materials for the reaction, which are usually located at the left-hand side of the energy diagram and have a certain energy level. Reactants are usually more stable than the intermediates or transition states, meaning that they have lower energy levels.
Products: The products are the end products of the reaction, which are usually located at the right-hand side of the energy diagram and have a different energy level than the reactants. Products are usually more stable than the intermediates or transition states, meaning that they have lower energy levels.
Parts of an energy diagram
Intermediate species: Intermediate species are any molecules or atoms that are formed during the reaction but are not the final products. These species are usually located at intermediate positions on the energy diagram, and their energy levels are higher than the reactants but lower than the transition states.
Activation energy: The activation energy is the minimum energy required for the reaction to occur. This is typically represented as a peak on the energy diagram and is located between the reactants and intermediates. The activation energy represents the energy barrier that must be overcome for the reaction to proceed. Higher activation energies lead to slower reaction rates.
Parts of an energy diagram
Delta G: Delta G (ΔG) is the change in Gibbs free energy during the reaction, which determines whether the reaction is exothermic or endothermic. A negative ΔG indicates an exothermic reaction, while a positive ΔG indicates an endothermic reaction. The value of ΔG can be calculated by subtracting the energy of the reactants from the energy of the products.
Using Energy Diagrams
Energy diagrams provide information about the energy changes that occur during a reaction and can be used to predict the rate and direction of the reaction. The activation energy determines the rate of the reaction, while the free energy change (ΔG) determines the thermodynamics and direction of the reaction. Intermediates and transition states provide information about the mechanism of the reaction. Energy diagrams are a powerful tool for designing and optimizing chemical reactions.
