UNI EDUCATION PRESENTATION

01

Non-lineardata structures

non-linear Data Structure

• A non-linear data structure is type in which data elements are not arranged sequentially; mainly, data elements are arranged in random order without forming a linear structure.
• Data elements are present at the multilevel, for example, tree and graphs.
• The non-linear data structure cannot be implemented directly, and it is implemented using the linear data structure like an array and linked list.

• The tree is a non-linear data structure that is comprised of various nodes. The nodes in the tree data structure are arranged in hierarchical order.
• It consists of a root node corresponding to its various child nodes, present at the next level. The tree grows on a level basis, and root nodes have limited child nodes depending on the order of the tree.
• For example, in the binary tree, the order of the root node is 2, which means it can have at most 2 children per node, not more than it

Write a subtitle here

tree

Write a subtitle here

Terminologies used in tree

Phasellus at viverra risus. Vivamus vulputate consequat.

• Root node: The tree consists of a root node; it is the starting node of the tree from which any tree grows. The root node is present at level 0 in any tree.
• Child node: The child node is the node that comes after the root node, which has a parent node and has some ancestors. It is the node present at the next level of its parent node.
• Edge: Edges are nothing but the link between the parent node, and the children node is called the link or edge connectivity between two nodes.
• Siblings: The nodes having the same parent node is called siblings of each other.
• Leaf node: The leaf node is the node that does not have any child nodes. It is the termination point of any tree. It is also known as External nodes.

Lorem ipsum dolor sit

Phasellus at viverra risus. Vivamus vulputate consequat.

Phasellus at viverra risus. Vivamus vulputate consequat.

Lorem ipsum dolor sit

Lorem ipsum dolor sit

Lorem ipsum dolor sit

Phasellus at viverra risus. Vivamus vulputate consequat.

graphs

• A Graph is a non-linear data structure consisting of vertices and edges.
• The vertices are sometimes also referred to as nodes and the edges are lines or arcs that connect any two nodes in the graph. More formally a Graph is composed of a set of vertices( V ) and a set of edges( E ). The graph is denoted by G(E, V).
• Vertices: Vertices are the fundamental units of the graph. Sometimes, vertices are also known as vertex or nodes. Every node/vertex can be labeled or unlabelled.
• Edges: Edges are drawn or used to connect two nodes of the graph.Edges can connect any two nodes in any possible way.

Write a subtitle here

One node is connected with another node with an edge in a graph. The graph is a non-linear data structure consisting of nodes and edges and is represented by G ( V, E ), where V stahe set of vertices and E stands for the set of edges. The g

Write a subtitle here

classification of graphs

Lorem ipsum dolor sit

Phasellus at viverra risus. Vivamus vulputate consequat.

Unweighted Graph

• Where there is no value or weight associated with the edge.

Weighted Graph

• Graphs whose edges or paths have values. All the values seen associated with the edges are called weights. Edges value can represent weight/cost/length.
• Ex: To look for that shortest path to the office, the distance between two workstations in an office network.

Phasellus at viverra risus. Vivamus vulputate consequat.

Lorem ipsum dolor sit

Directed graphs

• Also called a digraph
• where a set of nodes are or vertices connected together with each otherand edges have a direction from one vertex to another.

Undirected graphs

• It is set of nodes or vertices which are connected with no direction.

sit

sequat.

Lorem ipsum dolor sit

Phasellus at viverra risus. Vivamus vulputate consequat.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Integer odio turpis, varius vitae tempor vel, venenatis vel lectus.
