CAHV Addressing
Single unit addressing
Main
Sub
Address 051
Address 01
Single unit addressing
If there is more than one unit with the same address the overall system will flag a 6600 error.
Main
Sub
Address 051
Address 01
Sub unit is always 50 more than the main unit
Main unit is the lower addressed unit
