night vision technology

NAME: THARPAYNTHI.VDEPARTMENT: CSE YEAR: III

DATE:11/11/2021

INDEX

  • GENERATIONS
  • PROS AND CONS
  • APPLICATION
  • CONCLUSION
  • REFERENCE
  • INTRODUCTION
  • TYPES OF NIGHT VISION
  • NIGHT VISION DEVICES
  • WORKING

INTRODUCTION

  • Night vision tehnology,literally allows one to see in the dark.
  • It is originally developed for military use.
  • Humans have poor night vision compared to many other animals
  • With the proper night-vision equipment,we can see a person standing over 200 yards(183 m) away on a moonless,cloudy night.

types of Night vision technology

  • Biological Night Vision
  • Technical Night Vision

NIGHT VISION DEVICES

NIGHT VISION DEVICES ARE BASICALLY DIVIDED INTO THREE TYPES

  • SCOPES
  • GOGGLES
  • CAMERAS

SCOPES

THEY ARE MONOCULAR NORMALLY HANDHELD OR MOUNTED ON A WEAPON.

goggles

  • THEY ARE BINOCULAR AND WORN ON THE HEAD.
  • Night vision goggles useThermal imaging technology to capture that infrared light.

cameras

USED FOR TRANSMISSION OR RECORDING OF IMAGES MOSTLY IF THE LOCATION IS FIXED.

WORKING

IMAGE INTENSIFIER

WORKING

THERMAL IMAGING PROCESS

10

GENERATIONS

GENERATION 0

THE EARLIEST (1950'S) NIGHT VISION PRODUCT WERE BASED ON IMAGE CONVERSION, RATHER THAN INTENSIFICATION.

GENERATION 1

  • VACUUM TUBE TECHNOLOGY
  • FULL MOON OPERATION
  • AMPLIFICATION: 1,000
  • OPERATING LIFE:2,000 HOURS

11

GENERATION 2

  • FIRST MICRO CHANNEL PLATE APPLICATION
  • ONE-QUARTER MOON OPERATION
  • AMPLIFICATION: 20,000
  • OPERATING LIFE:2,500 HOURS

GENERATION 3

  • IMPROVED MICRO CHANNEL PLATE & PHOTOCATHODE
  • STARLIGHT OPERATION
  • AMPLIFICATON: 40,000
  • OPERATION LIFE:10,000 HOURS

12

PROS

MORE NATURAL IMAGES

LONGER BATTERY LIFE

See through smoke/fog/dust/sand

WIDER FIELD OF VIEW(FOV)

CONS

MORE EXPENSIVE

LONG START UP AND WARM UP TIME

LARGER OR HEAVIER

IMAGE REQUIRES SOME TRAINING TO INTERPRET

13

APPLICATION

  • MILITARY
  • HUNTING
  • WILDLIFE OBSERVATION
  • SECURITY
  • HIDDEN-OBJECT DETECTION

14

CONCLUSION

  • Today in the 21st century we have come a long way in the development of night vision technology,from the early 1940's.
  • Night vision device are basically designed for defensive purposes but the application within the scientific or the civilian range is often prohibited by law.
  • In present scenario the applications of night vision technology is very essential to combat terrorism which is a major problem being faced by mankind.

15

THANK YOU
