UCB

GESTIÓN DE CALIDAD DE SISTEMAS

Chapter 2- Testing Throughout the Software Development Lifecycle

START

by Katty Ode

INDEX

3. Test Types

1. Software Development Lifecycle Models

2. Test Levels

4. Maintenance Testing

Chapter 02

Testing throughout the software life cycle

Objetive: Understand the relationship between development, test activities and work products in the development life cycle, learn levels of testing

Software Development Models

Testing is not a stand-alone activity.
It has its place within a software development life cycle model and therefore the lifecycle applied will largely determine how testing is organized.
There are numerous development life cycles that have been developed in order to achieve different required objectives.

In every development life cycle, a part of testing is focused on verification testing and a part is focused on validation testing

Verification is concerned with evaluating a work product, component or system to determine whether it meets the requirements: is the deliverable built according the specification? Validation is concerned with the evaluating a work product, component or system to determine whether it meets the user need and requirements: is the deliverable fit for purpose? Does it provide a solution to the problem?

VERIFICATION

VALIDATION

SOFTWARE DEVELOPMENT MODELS

V-MODEL

4 test levels
Component testing
Integration testing
System testing
Acceptance testing

ITERATIVE LIFE CYCLES

Rapid Application Development
Dynamic system Development methodology
Agile development

2.1.1. V-MODEL

Before discussing V-model --- Waterfall model was one of the earliest models to be designed it has a natural timeline where tasks are executed in a sequential fashion, testing tends to happened at the end of the project life. The V-model was developed to address some of the problems experienced using the traditional waterfall approach. Defects were being found too late in the life cycle, as testing was not involved until the end of the project.

The V-model provides guidance that testing needs to begin as early as possible in the life cycle There are a variety of activities that need to be performed before the end of the coding phase. These activities should be carried out in parallel The V-model is a model that illustrates how testing activities (verification and validation) can be integrated into each phase of the life cycle

2.1.1. V-MODEL

2.1.1 V-MODEL

Although variants of the V-model exist,a common type of V-model uses four test levels.

2.1.1. V-MODEL

Acceptance testing: validation testing with respect to user needs, requirements, and business processes conducted to determine whether or not to accept the system. System testing: concerned with the behavior of the whole system/product as defined by the scope of a development project or product. The main focus of system testing is verification against specified requirements;

2.1.1. V-MODEL

Integration testing: tests interfaces between components, interactions to different parts of a system such as an operating system, file system and hardware or interfaces between systems Component testing: searches for defects in and verifies the functioning of software components (e.g. modules, programs, objects, classes etc.) that are separately testable;

2.1.1. V-MODEL

Acceptance testing

User

Component testing

System testing

Integration testing

Not all life cycles are sequential. There are also iterative or incremental life cycles where, instead of one large development timeline from beginning to end, we cycle through a number of smaller self-contained life cycle phases for the same project A common feature of iterative approaches is that the delivery is divided into increments or builds with each increment adding new functionality.

2.1.2. ITERATIVE LIFE CYCLES

The initial increment will contain the infrastructure required to support the initial build functionality. Subsequent increments will need testing for the new functionality, regression testing of the existing functionality, and integration testing of both new and existing parts.

2.1.2. ITERATIVE LIFE CYCLES

•Regression testing is increasingly important on all iterations after the first one. This means that more testing will be required at each subsequent delivery phase which must be allowed for in the project plans. • This life cycle can give early market presence with critical functionality, can be simpler to manage because the workload is divided into smaller pieces,

2.1.2. ITERATIVE LIFE CYCLES

Rapid Application Development

Rapid Application Development (RAD) is formally a parallel development of functions and subsequent integration.
Components/functions are developed in parallel as if they were mini projects the developments are time-boxed, delivered, and then assembled into a working prototype

2.1.2. ITERATIVE LIFE CYCLES

Rapid Application Development

This can very quickly give the customer something to see and use and to provide feedback regarding the delivery and their requirements.
Rapid change and development of the product is possible using this methodology.
This methodology allows early validation of technology risks and a rapid response to changing customer requirements

2.1.2. ITERATIVE LIFE CYCLES

Rapid Application Development

Dynamic System Development Methodology [DSDM] is a refined RAD process that allows controls to be put in place in order to stop the process from getting out of control.
From the testing perspective we need to plan this very carefully and update our plans regularly as things will be changing very rapidly

2.1.2. ITERATIVE LIFE CYCLES

agile development

Extreme Programming (XP) is currently one of the most well-known agile development life cycle models. The methodology claims to be more human friendly than traditional development methods.

It promotes the generation of business stories to define the functionality. It demands an on-site customer for continual feedback and to define and carry out functional acceptance testing. It promotes pair programming and shared code ownership amongst the developers. It states that component test scripts shall be written before the code is written and that those tests should be automated. It states that integration and testing of the code shall happen several times a day. It states that we always implement the simplest solution to meet today’s problems.

extreme programming (xp)

Some characteristics of XP are:

2.1.2. ITERATIVE LIFE CYCLES

agile development

Scrum: Each iteration tends to be relatively short (e.g., hours, days, or a few weeks), and the feature increments are correspondingly small, such as a few enhancements and/or two or three new features Kanban: Implemented with or without fixed-length iterations, which can deliver either a single enhancement or feature upon completion, or can group features together to release at once

2.1.3 Testing within a life cycle model

In summary, whichever life cycle model is being used, there are several characteristics of good testing:

for every development activity there is a corresponding testing activity;
each test level has test objectives specific to that level;
the analysis and design of tests for a given test level should begin during the corresponding development activity;
testers should be involved in reviewing documents as soon as drafts are available in the development cycle.

Question 1 of 4

Which one of the following is the BEST definition of an incremental development model? a) Defining requirements, designing software and testing are done in phases where in each phase a piece of the system is added b) A phase in the development process should begin when the previous phase is complete c) Testing is viewed as a separate phase which takes place after development has been completed d) Testing is added to development as an increment Select ONE option.

Rightanswer

This page is password protected

Enter the password

Question 3 of 4

What are good practices for testing within the development life cycle? a) Early test analysis and design. b) Different test levels are defined with specific objectives. c) Testers will start to get involved as soon as coding is done. d) A and B above.

Rightanswer

Question 4 of 4

Which option best describes objectives for test levels with a life cycle model? a) Objectives should be generic for any test level. b) Objectives are the same for each test level. c) The objectives of a test level don’t need to be defined in advance. d) Each level has objectives specific to that level.

Rightanswer

end day 4

2.2 TEST LEVELS

Test levels are groups of test activities that are organized and managed together. Each test level is an instance of the test process, performed in relation to software at a given level of development, from individual units or components to complete systems. For every test level, a suitable test environment is required. In acceptance testing, for example, a production-like test environment is ideal, while in component testing the developers typically use their own development environment.

test levels

Acceptance testing

User

Component testing

System testing

Integration testing

2.2 TESTING LEVELS

Also known as unit, module and program testing, searches for defects in, and verifies the functioning of software (e.g. modules, programs, objects, classes, etc.) that are separately testable.Component testing is often done in isolation from the rest of the system depending on the context of the development life cycle and the system.

COMPONENT TESTING

2.2 TESTING LEVELS

Typically, component testing occurs with access to the code being tested and with the support of the development environment, such as a unit test frame-work or debugging tool, and in practice usually involves the programmer who wrote the code. Sometimes, depending on the applicable level of risk, component testing is carried out by a different programmer thereby introducing independence. Defects are typically fixed as soon as they are found, without formally recording the incidents found.

COMPONENT TESTING

Component testing

Reducing risk
Verifying whether the functional and non-functional behaviors of the component are as designed and specified
Building confidence in the component’s quality
Finding defects in the component
Preventing defects from escaping to higher test levels

In some cases, especially in incremental and iterative development models (e.g., Agile) where code changes are ongoing, automated component regression tests play a key role in building confidence that changes have not broken existing components.

OBJECTIVES

Component testing

TEST BASIS

Examples of work products that can be used as a test basis for component testing include:

Detailed design
Code
Data model
Component specifications

Component testing

TEST OBJECTS

Typical test objects for component testing include:

Components, units or modules
Code and data structures
Classes
Database modules

Component testing

TYPICAL DEFECTS AND FAILURES

Examples of typical defects and failures for component testing include:

Incorrect functionality (e.g., not as described in design specifications)
Data flow problems
Incorrect code and logic

2.2 TESTING LEVELS

INTEGRATIONTESTING

Tests interfaces between components, interactions to different parts of a system such as an operating system, file system and hardware or interfaces between systems. There are two different levels of integration testing which may be carried out on test objects of varying size"

Component integration testing
System integration testing

Component integration testing focuses on the interactions and interfaces between integrated components. Component integration testing is performed after component testing, and is generally automated. In iterative and incremental development, component integration tests are usually part of the continuous integration process. System integration testing focuses on the interactions and interfaces between systems, packages, and microservices. System integration testing can also cover interactions with, and interfaces provided by, external organizations (e.g., web services). System integration testing may be done after system testing or in parallel with ongoing system test activities (in both sequential development and iterative and incremental development)

2.2 TESTING LEVELS

INTEGRATIONTESTING

2.2 TESTING LEVELS

Component integration tests and system integration tests should concentrate on the integration itself. Component integration testing is often the responsibility of developers. System integration testing is generally the responsibility of testers. Ideally, testers performing system integration testing should understand the system architecture, and should have influenced integration planning.

INTEGRATIONTESTING

2.2 TESTING LEVELS

The greater the scope of integration, the more difficult it becomes to isolate failures to a specific interface, which may lead to an increased risk. This leads to varying approaches to integration testing. One extreme is that all components or systems are integrated simultaneously, after which everything is tested as a whole. This is called ‘big-bang’ integration testing. Big-bang testing has the advantage that everything is finished before integration testing starts. There is no need to simulate (as yet unfinished) parts. The major disadvantage is that in general it is time-consuming and difficult to trace the cause of failures with this late integration.

INTEGRATIONTESTING

Another extreme is that all programs are integrated one by one, and a test is carried out after each step (incremental testing). Between these two extremes, there is a range of variants. The incremental approach has the advantage that the defects are found early in a smaller assembly when it is relatively easy to detect the cause. A disadvantage is that it can be time-consuming

Top-down: testing takes place from top to bottom, following the control flow or architectural structure
Bottom-up: testing takes place from the bottom of the control flow upwards.
Functional incremental: integration and testing takes place on the basis of the functions or functionality, as documented in the functional specification.

2.2 TESTING LEVELS

INTEGRATIONTESTING

INTEGRATION testing

Reducing risk
Verifying whether the functional and non-functional behaviors of the interfaces are as designed and specified
Building confidence in the quality of the interfaces
Finding defects (which may be in the interfaces themselves or within the components or systems)
Preventing defects from escaping to higher test levels

As with component testing, in some cases integration regression tests provide confidence that changes have not broken existing interfaces, components, or systems.

OBJECTIVES

INTEGRATION testing

TEST BASIS

Examples of work products that can be used as a test basis for integration testing include:

Software and system design
Sequence diagrams
Interface and communication protocol specifications
Use cases
Architecture at component or system level
Workflows
External interface definitions

INTEGRATION testing

TEST OBJECTS

Typical test objects for integration testing include:

Subsystems
Databases
Infrastructure
Interfaces
APIs
Microservices

INTEGRATION testing

TYPICAL DEFECTS AND FAILURES

Component integration testing examples:

Incorrect data, missing data, or incorrect data encoding
Incorrect sequencing or timing of interface calls
Interface mismatch
Failures in communication between components
Unhandled or improperly handled communication failures between components
Incorrect assumptions about the meaning, units, or boundaries of the data being passed between components

INTEGRATION testing

TYPICAL DEFECTS AND FAILURES

System integration testing examples:

Inconsistent message structures between systems
Incorrect data, missing data, or incorrect data encoding
Interface mismatch
Failures in communication between systems
Unhandled or improperly handled communication failures between systems
Incorrect assumptions about the meaning, units, or boundaries of the data being passed between
systems
Failure to comply with mandatory security regulations

2.2 TESTING LEVELS

System testing focuses on the behavior and capabilities of a whole system or product, often considering the end-to-end tasks System testing is most often the final test on behalf of development to verify that the system to be delivered meets the specification and its purpose may be to find as many defects as possible

SYSTEMTESTING

system testing

Reducing risk
Verifying whether the functional and non-functional behaviors of the system are as designed and specified
Validating that the system is complete and will work as expected
Building confidence in the quality of the system as a whole
Finding defects
Preventing defects from escaping to higher test levels or production

For certain systems, verifying data quality may also be an objective. System testing often produces information that is used by stakeholders to make release decisions. System testing may also satisfy legal or regulatory requirements or standards.

OBJECTIVES

SYSTEM testing

TEST BASIS

Examples of work products that can be used as a test basis for system testing include:

System and software requirement specifications (functional and non-functional)
Risk analysis reports
Use cases
Epics and user stories
Models of system behavior
State diagrams
System and user manuals

SYSTEM testing

TEST OBJECTS

Typical test objects for system testing include:

Applications
Hardware/software systems
Operating systems
System under test (SUT)
System configuration and configuration data

SYSTEM testing

TYPICAL DEFECTS AND FAILURES

Examples of typical defects and failures for system testing include:

Incorrect calculations
Incorrect or unexpected system functional or non-functional behavior
Incorrect control and/or data flows within the system
Failure to properly and completely carry out end-to-end functional tasks
Failure of the system to work properly in the system environment(s)
Failure of the system to work as described in system and user manuals

2.2 TESTING LEVELS

When the development organization has performed its system test and has corrected all or most defects, the system will be delivered to the user or customer for acceptance testing. The acceptance test should answer questions such as: ‘Can the system be released?’ Defects may be found during acceptance testing, but finding defects is often not an objective, and finding a significant number of defects during acceptance testing may in some cases be considered a major project risk.

ACCEPTANCETESTING

2.2 TESTING LEVELS

Common forms of acceptance testing include the following:

User acceptance testing
Operational acceptance testing
Contractual and regulatory acceptance testing
Alpha and beta testing.

ACCEPTANCETESTING

ACCEPTANCE TESTING

User acceptance testing of the system is typically focused on validating the fitness for use of the system by intended users in a real or simulated operational environment. The main objective is building confidence that the users can use the system to meet their needs, fulfill requirements, and perform business processes with minimum difficulty, cost, and risk.

User acceptance testing (UAT)

ACCEPTANCE TESTING

Operational acceptance testing (OAT)

The acceptance testing of the system by operations or systems administration staff is usually performed in a (simulated) production environment. The tests focus on operational aspects, and may include:

Testing of backup and restore
Installing, uninstalling and upgrading
Disaster recovery
User management
Maintenance tasks
Data load and migration tasks
Checks for security vulnerabilities
Performance testing

The main objective of operational acceptance testing is building confidence that the operators or system administrators can keep the system working properly for the users in the operational environment, even under exceptional or difficult conditions

ACCEPTANCE TESTING

Contractual acceptance testing is performed against a contract’s acceptance criteria for producing custom-developed software. Acceptance criteria should be defined when the parties agree to the contract.
Contractual acceptance testing is often performed by users or by independent testers.
Regulatory acceptance testing is performed against any regulations that must be adhered to, such as government, legal, or safety regulations.
Regulatory acceptance testing is often performed by users or by independent testers, sometimes with the results being witnessed or audited by regulatory agencies.

Contractual and regulatory acceptance testing

ACCEPTANCE TESTING

If the system has been developed for the mass market, e.g. commercial off-the-shelf software (COTS), then testing it for individual users or customers is not practical or even possible in some cases.
Feedback is needed from potential or existing users in their market before the software product is put out for sale commercially. Very often this type of system undergoes two stages of acceptance test.
The first is called alpha testing. This test takes place at the developer’s site. A cross-section of potential users and members of the developer’s organization are invited to use the system. Developers observe the users and note problems. Alpha testing may also be carried out by an independent test team.

Alpha and beta testing

ACCEPTANCE TESTING

Beta testing, or field testing, sends the system to a cross-section of users who install it and use it under real-world working conditions. The users send records of incidents with the system to the development organization where the defects are repaired

One objective of alpha and beta testing is building confidence among potential or existing customers, and/or operators that they can use the system under normal, everyday conditions, and in the operational environment(s) to achieve their objectives with minimum difficulty, cost, and risk. Another objective maybe the detection of defects related to the conditions and environment(s) in which the system will be used, especially when those conditions and environment(s) are difficult to replicate by the development team

Alpha and beta testing

aCCEPTANCE testing

Establishing confidence in the quality of the system as a whole
Validating that the system is complete and will work as expected
Verifying that functional and non-functional behaviors of the system are as specified

Acceptance testing may produce information to assess the system’s readiness for deployment and use by the customer (end-user).

OBJECTIVES

Acceptance testing

TEST BASIS

Examples of work products that can be used as a test basis for acceptance testing include:

Business processes
User or business requirements
Regulations, legal contracts and standards
Use cases and/or user stories
System requirements
System or user documentation
Installation procedures
Risk analysis reports

Acceptance testing

TEST BASIS

In addition, as a test basis for deriving test cases for operational acceptance testing, one or more of the following work products can be used

Backup and restore procedures
Disaster recovery procedures
Non-functional requirements
Operations documentation
Deployment and installation instructions
Performance targets
Database packages
Security standards or regulations

ACCEPTAnCE testing

TEST OBJECTS

Typical test objects for acceptance testing include:

System under test
System configuration and configuration data
Business processes for a fully integrated system
Recovery systems and hot sites (for business continuity and disaster recovery testing)
Operational and maintenance processes
Forms
Reports
Existing and converted production data

ACCEPTANCE testing

TYPICAL DEFECTS AND FAILURES

Examples of typical defects and failures for acceptance testing include:

System workflows do not meet business or user requirements
Business rules are not implemented correctly
System does not satisfy contractual or regulatory requirements
Non-functional failures such as security vulnerabilities, inadequate performance efficiency under high loads, or improper operation on a supported platform

end day 5

TEST LEVELS

Acceptance testing

User

Component testing

System testing

Integration testing

Question 1 of 3

What type of testing is normally conducted to verify that a product meets a particular regulatory requirement? a. Unit testing b. Integration testing c. System testing d. Acceptance testing

Rightanswer

Question 2 of 3

Consider the following types of defects that a test level might focus on: 1. Defects in separately testable modules or objects 2. Not focused on identifying defects 3. Defects in interfaces and interactions 4. Defects in the whole test object Which of the following list correctly matches test levels from with the defect focus options given above? a) 1 = performance test; 2 = component test; 3 = system test; 4 = acceptance test b) 1 = component test; 2 = acceptance test; 3 = system test; 4 = integration test c) 1 = component test; 2 = acceptance test; 3 = integration test; 4 = system test d) 1 = integration test; 2 = system test; 3 = component test; 4 = acceptance test Select ONE option.

Rightanswer

Question 3 of 3

Given that the testing being performed has the following attributes: • Based on interface specifications • Focused on finding failures in communication • Use incremental testing Which of the following test levels is MOST likely being performed? a) Integration testing b) Acceptance testing c) System testing d) Component testing

Rightanswer

2.3 TEST TYPES

A test type is focused on a particular test objective.

Evaluating functional quality characteristics, such as completeness, correctness, and appropriateness
Evaluating non-functional quality characteristics, such as reliability, performance efficiency, security, compatibility, and usability

2.3 TEST TYPES

A test type is focused on a particular test objective.

Evaluating whether the structure or architecture of the component or system is correct, complete, and as specified
Evaluating the effects of changes, such as confirming that defects have been fixed (confirmation testing) and looking for unintended changes in behavior resulting from software or environment changes (regression testing)

2.3 Test TYPES

Functional testing of a system involves tests that evaluate functions that the system should perform.
The functions are “what” the system should do.
Function (or functionality) testing can be done focusing on suitability, interoperability, security, accuracy and compliance
Suitability: Adecuación
Interoperability: Interoperabilidad
Security: Seguridad
Accuracy: Precisión
Compliance: Cumplimiento

FUNCTIONAL TESTING

2.3 Test TYPES

Functional requirements may be described in work products such as business requirements specifications, epics, user stories, use cases, or functional specifications.
Functional tests should be performed at all test levels

FUNCTIONAL TESTING

2.3 Test TYPES

Requirements-based testing uses a specification of the functional requirements for the system as the basis for designing tests.
We should also prioritize the requirements based on risk criteria (if this is not already done in the specification) and use this to prioritize the tests. This will ensure that the most important and most critical tests are included in the testing effort.

FUNCTIONAL TESTING - examples

2.3 Test TYPES

Business-process-based testing uses knowledge of the business processes. Business processes describe the scenarios involved in the day-to-day business use of the system
They also take the business processes as a starting point, although they start from tasks to be performed by users. Use cases are a very useful basis for test cases from a business perspective.

FUNCTIONAL TESTING

2.3 Test TYPES

Functional test design and execution may involve special skills or knowledge, such as knowledge of the particular business problem the software solves

FUNCTIONAL TESTING

2.3 Test TYPES

A second target for testing is the testing of the quality characteristics, or non-functional attributes of the system (or component or integration group). Here we are interested in how well or how fast something is done.
Non-functional testing, as functional testing, should be performed at all test levels, and done as early as possible. The late discovery of non-functional defects can be extremely dangerous to the success of a project

NON-FUNCTIONAL TESTING

2.3 Test TYPES

Non-functional testing includes, but is not limited to, performance testing, load testing, stress testing, usability testing, maintainability testing, reliability testing and portability testing.

NON-FUNCTIONAL TESTING

2.3 Test TYPES

Testing of software structure/architecture (structural testing), Structural testing is often referred to as ‘white-box’ or ‘glass-box’ because we are interested in what is happening ‘inside the box’.
White-box testing derives tests based on the system’s internal structure or implementation. Internal structure may include code, architecture, work flows, and/or data flows within the system

WHITE-BOX TESTING

2.3 Test TYPES

At the component testing level, code coverage is based on the percentage of component code that has been tested, and may be measured in terms of different aspects of code such as the percentage of executable statements tested in the component, or the percentage of decision outcomes tested
At the component integration testing level, white-box testing may be based on the architecture of the system, such as interfaces between components.
White-box test design and execution may involve special skills or knowledge, such as the way the code is built, how data is stored and how to use coverage tools and to correctly interpret their results.

WHITE-BOX TESTING

2.3 Test TYPES

When changes are made to a system, either to correct a defect or because of new or changing functionality, testing should be done to confirm that the changes have corrected the defect or implemented the functionality correctly, and have not caused any unforeseen adverse consequences.

Confirmation testing
Regression testing

CHANGE-RELATED TESTING

2.3 Test TYPES

Confirmation testing (re-testing) When a test fails and we determine that the cause of the failure is a software defect, the defect is reported, and we can expect a new version of the software that has had the defect fixed. In this case we will need to execute the test again to confirm that the defect has indeed been fixed. This is known as confirmation testing (also known as re-testing).

CHANGE-RELATED TESTING

2.3 Test TYPES

When doing confirmation testing, it is important to ensure that the test is executed in exactly the same way as it was the first time, using the same inputs, data and environment. If the test now passes does this mean that the software is now correct? Well, we now know that at least one part of the software is correct – where the defect was. But this is not enough. The fix may have introduced or uncovered a different defect elsewhere in the software. The way to detect these ‘unexpected side-effects’ of fixes is to do regression testing.

CHANGE-RELATED TESTING

2.3 Test TYPES

Regression testing It is possible that a change made in one part of the code, whether a fix or another type of change, may accidentally affect the behavior of other parts of the code, whether within the same component, in other components of the same system, or even in other systems. Changes may include changes to the environment, such as a new version of an operating system or database management system. Such unintended side-effects are called regressions. Regression testing involves running tests to detect such unintended side-effects.

CHANGE-RELATED TESTING

2.3 Test TYPES

Confirmation testing and regression testing are performed at all test levels
It is common for organizations to have what is usually called a regression test suite or regression test pack. This is a set of test cases that is specifically used for regression testing. They are designed to collectively exercise most functions (certainly the most important ones) in a system but not test any one in detail. It is appropriate to have a regression test suite at every level of testing (component testing, integration testing, system testing, etc.). All of the test cases in a regression test suite would be executed every time a new version of software is produced and this makes them ideal candidates for automation.

CHANGE-RELATED TESTING
