Extraction of sucrose
6 steps to making sugar from sugar cane
Harvesting, Crushing and Milling: cane is cut from the fields, cleaned, cut with knives(shredded), crushed and hot water is added/sprayed to dissolve the sucrose from the cells. Dilute cane juice and fibres are produced. Click here,
GO!
Extraction of sucrose
6 steps to making sugar from sugar cane
2.Precipitation/Clarification: Calcium hydrdoxide,Ca(OH)2 (also called lime) is added WITH HEAT to neutralize the acidic juice, precipitate out the sediment impurities and prevent the breakdown of the sucrose to glucose and fructose. Click here
GO!
Extraction of sucrose
6 steps to making sugar from sugar cane
3. Filtration: the non-sugar impurities precipitated out from step 2 are filtered out from the CLARIFIED JUICE. They are washed to extract any sucrose present and returned to the fields to be used as fertilizer. Click here.
GO!
Extraction of sucrose
6 steps to making sugar from sugar cane.
4. Vacuum Distillation/Evaporation: The clarified juice which is about 85% water is concentrated by boiling in a series of evaporators under reduced pressure. This method prevents the juice from charring or becoming caramelized. Click here.
GO!
Extraction of sucrose
6 steps to making sugar from sugar cane
5. Crystallisation: The thick syrup is boiled again at low pressure in vacuum pans to remove more water. A mixture of sugar crystals and molasses are formed, collectively called MASSECUITE. Click here.
GO!
Extraction of sucrose
I did it!!! I made sugar!! Click here to see a video on the process
6 steps to making sugar from sugar cane
6. Centrifugation: High speed rotation separates sugar crystals from molasses. Unrefined sugar is sold locally or exported. Molasses is used to make rum and animal feed.
View these videos which are visual representations of the process you just looked at in the steps before. Note in the first video there may be extra steps as each sugar industry would have made its own modifications to the basic process.
